CraftBot CB4 FLOW Series User Manual page 15

•
Sound
•
After touching the second button (Sound)
in the top submenu, a new screen appears
again.
•
In the menu, you can turn the volume on
or off and the slider to adjust the volume.
•
Time
•
After touching the third button (Time) in
the top submenu, a new screen appears
again.
•
Set the time of the zone to determine
the current time.
6.4. Printing modes
Select the Settings menu
•
Default mode: Gcode will determine whether the printer operates with one or two
printheads. If an object was sliced for a single head printer, but contains a support
struction, the CtaftBot 3 is able to print the object with normal filament while printing
the support with PVA filament. The advantage to this is that you don't have to re-slice
the existing gcodes if you also wants to print with PVA.
•
Mirrored printing: If an object fits on half of the build platform, then there is the option
of printing two objects at once which will be mirror images of one another. This way,
two objects can be made in time it takes to print one object. For example, if printing a
hand, the printer can make a right and a left hand at the same time. If a symmetrical
object is being created (a heart, for example), both halves can be printed at once and
the entire object can be prepared in the time it takes to print half an object.
•
Parallel printing: If an object fits on half of the build platform, there is the option of
printing two objects at once that will be completely identical. This way, two objects
can be made in time it takes to print one object. The printer's productivity is therefore
doubled.
•
Support printing: If a model has been sliced for a 1 headed printer and it contains
supports, then the printer will recognize the supports automatically and will print
them with the 2. head. With this mode you can print supports with soluble material
without re-slicing the model.
on the LCD screen and touch the Mode icon.
15
