Note:
Please read the complete description before starting the installation. Make sure
that connectors are properly sealed against water if no cables are connected to
them after installation.

1. Assembly

Fit these seven parts above together and fasten them with screws M6, nuts M6, spring
washers, and washers.
Page 1
Installation Guide for
CMAX-DMF3-43-Ci53 Antenna
Installation Instruction for CMAX Antennas
M0153A5A_InstInstr_CMAX-DMF3-43-Ci53

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CMAX-DMF3-43-Ci53 and is the answer not in the manual?

Questions and answers

Summary of Contents for CommScope CMAX-DMF3-43-Ci53

  • Page 1 Installation Instruction for CMAX Antennas Installation Guide for CMAX-DMF3-43-Ci53 Antenna Note: Please read the complete description before starting the installation. Make sure that connectors are properly sealed against water if no cables are connected to them after installation. 1. Assembly Fit these seven parts above together and fasten them with screws M6, nuts M6, spring washers, and washers.
  • Page 2 Installation Instruction for CMAX Antennas 2. Wall Mounting 1. Use this pedestal piece as a drill jig to mark 4 holes onto the wall as shown in the drawing above. 2. Drill 4 holes into the wall and insert expansion bolts into the holes. 3.
  • Page 3 © Copyright 2020 CommScope, Inc. All rights reserved. All information contained in this manual has been revised thoroughly. Yet CommScope accepts no liability for any omissions or faults. CommScope reserves the right to change all hardware and software characteristics without notice.
