INSTALLATION & OWNER'S MANUAL
Direct Vent Gas Insert Fireplace
785YN (natural gas) & 785YP (propane gas)
DANGER
!
A barrier designed to reduce the risk of burns from the hot
viewing glass is provided with this appliance and must be
installed for the protection of children and other at-risk
individuals.
!
WARNING
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly
could result in serious injury, death, or
property damage.
— Do not store or use gasoline or other
fl ammable vapors and liquids in the
vicinity of this or any other appliance.
— WHAT TO DO IF YOU SMELL GAS
▪ Do not try to light any appliance.
▪ Do not touch any electrical switch; do
not use any phone in your building.
▪ Leave the building immediately.
▪ Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
▪ If you cannot reach your gas supplier,
call the fi re department.
— Installation and service must be
performed by a qualifi ed installer,
service agency or the gas supplier.
4006267-08
©2020, Miles Industries Ltd.
G4
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
with
Please read this manual
BEFORE
operating this appliance.
INSTALLER
Leave this manual
with the appliance.
CONSUMER
Retain this manual
for future reference.
This manual contains instructions to install the
ENGINE ONLY. A front is also REQUIRED to
complete this installation. A barrier screen is pro-
vided with the front. Refer to the manual sup-
plied with the front for installation.
This appliance may be installed in an after-
market permanently located, manufactured
(mobile) home where not prohibited by local
codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in
a bedroom or bed sitting room.
Ce guide est disponible en français sur demande.
Canadian Patent 2717779
US and other patents
pending
installing and

Advertisement

Table of Contents
loading

Related Manuals for Valor G4 Series

Summary of Contents for Valor G4 Series

  • Page 1 INSTALLATION & OWNER’S MANUAL with Direct Vent Gas Insert Fireplace Canadian Patent 2717779 US and other patents 785YN (natural gas) & 785YP (propane gas) pending DANGER Please read this manual BEFORE installing and operating this appliance. HOT GLASS WILL CAUSE BURNS. INSTALLER DO NOT TOUCH GLASS Leave this manual...

  • Page 2: Table Of Contents

    fi tter in the State assumes no responsibility for any consequential of Massachusetts. damage(s). Designed and Manufactured by / for Miles Industries Ltd. 190–2255 Dollarton Highway, North Vancouver, BC, CANADA V7H 3B1 Tel. 604-984-3496 Fax 604-984-0246 www.valorfi replaces.com...

  • Page 3: Safety And Your Fireplace

    Safety and Your Fireplace SAFETY AND YOUR FIREPLACE Read and understand all instructions carefully before Do not use this heater as a temporary source of starting the installation. Failure to follow these instal- heat during construction. lation instructions may result in possible fi re hazard and Due to the high temperature, the appliance should be will void the warranty.
  • Page 4 Safety and Your Fireplace Read and carefully follow all safety warnings and operating instructions contained in your owner’s manual Replacement manuals are available by contacting the Valor Service Department at 1-800-468-2567 or visit www.valorfi replaces.com. FOLLOW THESE IMPORTANT CHILD SAFETY...
  • Page 5 SAFETY AND YOUR FIREPLACE This manual and particularly the preceeding and following pages contain very important information regarding before operating your the safe operation of your fi replace as well as maintenance instructions. Read carefully fi replace and pay special attention to the safety warnings. A heating gas appliance does require safe handling.

  • Page 6: Introduction

    Each Valor fi replace curing compounds used in the manufacture of the is fully tested during the production process for your appliance.

  • Page 7: Operating Your Fireplace

    OWNER’S Operating Your Fireplace INFORMATION Fireplace Control Devices If the fl ames are on, they go down and you hear the valve motor wind down. You hear a clunk and a beep There are three ways to control your fi replace. indicating that the valve has received the signal from 1.

  • Page 8: Using The Remote Control

    OWNER’S Using the Remote Control INFORMATION Radio Frequency Turn Fireplace ON 315 MHz for USA and Canada. Press buttons until you hear a short beep; release buttons. This device complies with Part 15 of the FCC Rules and with Industry Canada license-exempt RSS standard(s). Beeps continue until pilot is lit.
  • Page 9 OWNER’S Using the Remote Control INFORMATION Setting ºC/24-hr or ºF/12-hr Manual Mode M A N clock Manual ame height adjustment. In MAN mode, press buttons Daytime Temperature Mode until temperature / clock display TEMP changes from When pilot is lit, room temperature °F / 12-hour °C / 24-hour is measured and compared to set...
  • Page 10 OWNER’S Using the Remote Control INFORMATION Circulating Fan Operation Setting Program Timers (if equipped) You can program two periods of time between 12 am Circulating fan has 4 speed levels from and 11:50 pm in each 24-hour cycle. low to high (1 to 4 bars). Programs P1 and P2 must be set in the following order Press SET to scroll to .
  • Page 11 OWNER’S Using the Remote Control INFORMATION Setting P2 high and low temperature times. Repeat same steps as Setting P1. When all settings are complete, press to save them. Timer Programming Example (default temperatures shown) 6:00 am 8:00 am 4:00 pm 10:00 pm 6:00 am high temp...

  • Page 12: Kits & Accessories

    Refl ective glass panels Risers (2-1/2”) for 790/1/2/8 788FBLV2 Fluted black panels 794BPB Backing Plates Black for 790, 791, 792 & 794BPB-1 789VRLV2 Valor Red brick panels 795CFKV2 Circulating Fan Kit Barrier Front & Backing Plates (choose one) 796ALP Adjustable Leveling Platform Screen...

  • Page 13: Lighting Instructions

    OWNER’S Lighting Instructions INFORMATION FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly causing property damage, personal injury or loss of life. . To save gas, turn the pilot off when not using the appliance for a prolonged period of time. WHAT TO DO IF r’s phone.

  • Page 14: Servicing & Maintenance

    OWNER’S Servicing & Maintenance INFORMATION Servicing Your Fireplace We recommend having your fi replace serviced every year. Contact your supplier quoting the model number. It will be helpful if the appliance’s serial number can also be quoted. These numbers are on the information card.

  • Page 15: Cleaning Your Fireplace

    OWNER’S Servicing & Maintenance INFORMATION Cleaning Your Fireplace Clean the window panes following the guidelines in this section. WARNING Clean the steel trim with mild soap and warm water. DO NOT TOUCH THE GLASS WHILE IT IS HOT! Any alcohol/solvent base cleaner will weaken the coat- Let the fi...
  • Page 16 fi replace, damage components, cause overheating resulting in dangerous conditions. Safety warning plate Damage caused by incorrect window installa- tion is not covered by the Valor warranty. 1. Place the window in its bottom railing and push its top against Window 6.

  • Page 17: Checking Pilot And Burner Flames

    OWNER’S Servicing & Maintenance INFORMATION Checking Pilot and Burner Flames The appliance area must always be kept clear and free from combustible materials, gasoline and other A periodic check of the pilot and burner fl ames should fl ammable vapors and liquids. be made.

  • Page 18: Replacing Batteries

    OWNER’S Servicing & Maintenance INFORMATION Replacing Batteries 2. Disconnect the battery holder. WARNING DO NOT ATTEMPT TO CHANGE THE BATTER- IES WHILE THE FIREPLACE IS STILL HOT! Let the fi replace cool fi rst before touching it. CAUTION DO NOT USE a screwdriver or other metallic object to remove the batteries from the battery holder or the handset! This could cause a short circuit to the receiver.

  • Page 19: Specifi Cations

    QUALIFIED Specifi cations INSTALLER Approval & Codes Supply Gas This appliance is certifi ed to ANSI Z21.88 / CSA 2.33 Heater engine 785YN is used with natural gas. American National Standard / CSA Standard for Vented Heater engine 785YP is used with propane gas. Gas Fireplace Heaters for use in Canada and USA, The supply pressure must be between the limits shown and to CGA 2.17-91 High Altitude Standard in Canada.

  • Page 20: Overview

    QUALIFIED Overview INSTALLER This appliance may ONLY be installed in an existing unaltered, functioning solid-fuel burning fi replace with a working fl ue and constructed of non-combustible material. DO NOT install into combustible construction. This appliance is NOT APPROVED for installation with a zero clearance kit. WARNING WARNING Some materials or items, although...

  • Page 21: Dimensions

    QUALIFIED Dimensions INSTALLER 33” (838 mm) 24” (610 mm) 3” 6’ (1.9 m) Fan power cord (76 mm) Optional fan 3” 3” 15” (76 mm) (76 mm) (381 mm) 15” Trim 4” (381 mm) (102 mm) (sold separately) 9-1/2” (241 mm) Gas line approx.

  • Page 22: Clearances

    QUALIFIED Clearances INSTALLER WARNING WARNING Some materials or items, although safe, may discolor, shrink, warp, crack, peel, and so on because of the heat produced by the fi replace. Avoid placing candles, paintings, photos, and other items sensitive to heat around the fi replace. Combustible Mantel Clearances Mantel Pro- 1”...

  • Page 23: Venting

    QUALIFIED Venting INSTALLER Typical Vent Installation See list of approved venting accessories on page 40 of this manual. NOTE: Flexible co-linear vent pipes may only be installed into existing non-combustible solid-fuel burning fi replaces and chimneys. Terminal Cap Vent Location The vent terminal must be located through the roof.

  • Page 24: Existing Fireplace Preparation

    QUALIFIED Installation Planning INSTALLER Only qualifi ed licensed or trained personnel should install this appliance. Installer—READ THIS FIRST 1. YOU NEED TO KNOW FROM THE 13. Refi t window. HOMEOWNER what accessories (surround, 14. Reinstall the hot glass warning plate if it has been screen, fan/blower, etc.) will be installed with removed.

  • Page 25: Installation

    QUALIFIED Existing Fireplace Preparation INSTALLER Gas Line Routing Combustible Mantels Plan the routing of the gas line before proceeding. Combustible mantel clearances must conform to those Utilize the existing hole for the gas line of the factory- required for the original solid-fuel fi replace into which built fi...

  • Page 26: Remove Window

    QUALIFIED Installation INSTALLER Remove Window The window is held in place by a spring-loaded lever on each side. 1. To remove the window, locate the levers on each side of the window towards the top. Using your fi nger, pull the lever towards you and unhook it from the window frame bracket.

  • Page 27: Connect Venting

    QUALIFIED Installation INSTALLER Connect Venting IMPORTANT: This appliance’s venting system is room sealed and therefore, does not require room air to be used in the combustion process. 1. Rough-in two 3” diameter vent liners into the existing chimney system from the roof. Be careful not to tear or damage the liners in the process.

  • Page 28: Connect Gas Supply

    QUALIFIED Installation INSTALLER Connect Gas Supply Pressure Test Points The gas supply inlet connection is a 1/2” NPT female. The minimum supply pressure is given in the section Gas shut-off valve supplied on the end of stainless Specifi cations of this manual—page 19. steel fl...
  • Page 29 QUALIFIED Installation INSTALLER Alternate Inlet Connection Use common elbow and fi ttings (not supplied) to redirect the position of In cases where local codes do not permit the fl ex the fl ex connector. NOTE: the fl ex connector to be used inside the appliance case, connector bend radius must be no reconnect the fl...

  • Page 30: Install Liner Panels

    QUALIFIED Installation INSTALLER Remove and re-install burner (if necessary) 2. Place the rear panel against the back of the fi rebox, on the ledge at bottom, behind the burner. The ceramic panels can be installed without removing the burner. However, you can remove the burner for additional space if desired.

  • Page 31: Install Driftwood Kit 1101Dwk

    QUALIFIED Installation INSTALLER Install Driftwood Kit 1101DWK 2. Place the right log on the right side of the ceramic burner inserting the two pegs of the log in the holes Material required of the burner. The rear end of the log rests on the •...
  • Page 32 Pebbles Place the pebbles on the platform as shown below. IMPORTANT: Use only the ceramic rocks approved for use with your Valor fi replace. Use of other rocks can damage your fi replace and void the warranty. WARNING CHOKING HAZARD! Ensure that the fi replace area is clear fi...

  • Page 33: Install Decorative Glass Murano 785Xdgm

    IMPORTANT: Use only the fi reglass approved for your Valor fi replace or the fi reglass brands Ameri- can Fireglass™ or fi regear. Use of other fi reglass or crushed glass can damage your fi replace and void the warranty.

  • Page 34: Refi T And Check Window

    Damage caused by incorrect window installa- tion is not covered by the Valor warranty. 5. If the Hot Glass Warning plate has been removed from the front lower corner of the window, reinstall it by sliding it between the glass and the frame as indicated below.

  • Page 35: Synchronize Remote Control

    QUALIFIED Installation INSTALLER Synchronize Remote Control 3. With a sharp object, press and hold the receiver’s reset button until you hear one short and one long The receiver and the handset of the remote control beep. Release the reset button after the second system must be initially synchronized before the fi...

  • Page 36: Check Operation

    QUALIFIED Installation INSTALLER Check Operation 3. Loosen the air shutter nuts, adjust and re-tighten. Turn the fi replace fl ame up and down using the remote control to confi rm that the full range of inputs is achieved—see the remote control operation instructions on pages 8–11.

  • Page 37: Install Side Shrouds

    QUALIFIED Installation INSTALLER Install Side Shrouds Door hinge tabs The side shrouds are required to install the front on should face inwards the appliance. They are supplied with the engine. Fit them to the appliance outer case as indicated (2 screws/side). See instructions supplied with the front trim for installation of trim.

  • Page 38: Wiring Diagram

    QUALIFIED Wiring Diagram INSTALLER Optional Wall Switch Kit 1265WSK Connector Yellow Optional Fan 795CFKV2 Control Module Battery Holder 4 AA Batteries GV60 Wiring Diagram...

  • Page 39: Approved Venting Components

    QUALIFIED Approved Venting Components INSTALLER Approved Direct Vent Suppliers for Valor Models 700 , 739 , 780 and 785 Venting Parts Code / availability by Manufacturer Venting Parts Description 4DVC 940264 HSDV4658- Standard Co-axial 46DVA-VC 4DT-VT — — 4DH-1313 —...

  • Page 40: Warranty

    Installation and maintenance must be performed by 5. No Other Warranty an authorized and trained dealer in accordance with All obligations to repair this unit are de ned in this warranty.

  • Page 41: Spare Parts

    Refl ective Glass 787RGL Pilot Assembly 51 (natural gas) 4006030 Ceramic fl uted black 788FBLV2 Pilot Assembly 30 (propane gas) 4006031 Valor red brick 789VRLV2 Thermocouple (1000 mm) 4004801 Top panel Pilot Injector #51 (natural gas) 4000735 Ledgestone V3 4007997...
  • Page 42 Number Left side panel Ledgestone V3 4007998 Refl ective Glass 4004708 Filler panel 4002776 Ceramic fl uted black 4002377 Valor red brick 4002382 Right side panel Ledgestone V3 4007999 Refl ective Glass 4004709 Filler panel 4002776 Ceramic fl uted black...
  • Page 43 OWNER’S Spare Parts INFORMATION 1101DWK 17 18 38 39 785XDGM 30–31 26–29...
