Installation & Operating Instructions
WARNING: If the information in these
instructions is not followed exactly, a fire
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fire department.
Installation and service must be performed
by a qualified installer, service agency or the
gas supplier.
4002263-03
©2010, Miles Industries Ltd.
L
egend
Direct Vent Gas Insert
785ILN (NG) & 785ILP (LPG)
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfireplaces.com
g4
INSTALLER: Leave this manual
with the appliance.
CONSUMER: Retain this manual
for future reference.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certified kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and final
gas connection must be performed by a
licensed plumber or gas fitter in the State of
Massachusetts.
Ce guide est disponible en français sur demande.
Patent Pending
Advertisement
Table of Contents
Related Manuals for Valor 785ILN
Summary of Contents for Valor 785ILN
- Page 1 Patent Pending Direct Vent Gas Insert 785ILN (NG) & 785ILP (LPG) Installation & Operating Instructions HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. INSTALLER: Leave this manual with the appliance. NEVER ALLOW CHILDREN CONSUMER: Retain this manual TO TOUCH GLASS.
- Page 2 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Each Valor fireplace is fully tested during the production process for your safety and comfort.
-
Page 3: Table Of Contents
Table of Content Safety and Warning Information..............4 ◊ Specifications ....................5 Overview ......................6 Dimensions ....................7 Cavity ......................7 Clearances ......................8 Venting ......................9 Installation Planning ..................10 Existing Fireplace Preparation ..............10 Appliance Preparation .................11 Supply Gas Installation ................14 Burner Removal and Reinstall ..............15 Ceramic Panels Installation ................15 Ceramic Logs Installation ................16 Window Refitting ..................18 Remote Control Initial Set-up ..............19... -
Page 4: Safety And Warning Information
Safety and Warning Information READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fire system or components MAY BE USED. -
Page 5: Specifications
Installation Code CAN/CGA-B149. Only qualified Supply Gas licensed or trained personnel should install this Heater engine 785ILN is used with natural gas. appliance. Heater engine 785ILP is used with propane gas. This appliance must be electrically grounded in... -
Page 6: Overview
Overview This appliance may ONLY be installed in an existing unaltered, functioning solid-fuel burning fireplace with a working flue and constructed of non-combustible material. DO NOT install into combustible construction. This appliance is NOT APPROVED for installation with a zero clearance kit. Chimney Terminal Cap Flashing 2 x 3”... -
Page 7: Dimensions
Dimensions 33” (838 mm) 24” (610 mm) 6’ (1.9 m) Fan power cord 3” (76 mm) Optional fan 3” 3” 15” (76 mm) (76 mm) (381 mm) 15” 4” Trim (381 mm) (102 mm) (sold separately) Gas line approx. 24“ (610 mm) 10”... -
Page 8: Clearances
Clearances WARNING Some materials or items, although safe, may discolor, warp, crack, peel, and so on because of the heat produced by the fireplace. Avoid placing candles, paintings, photos, and other items sensitive to heat around the fireplace. Combustible Mantel Clearances Mantel 1”... -
Page 9: Venting
Venting Typical Vent Installation See list of approved Venting Accessories on page 32 of this manual. NOTE: Flexible co-linear vent pipes may only be installed into existing non- combustible solid-fuel burning fireplaces and chimneys. Terminal Cap Vent Location The vent terminal must be located through the roof. -
Page 10: Installation Planning
Installation Planning Installer—READ THIS FIRST 14. Install ceramic panels and logs. 15. Refit window. 1. YOU NEED TO KNOW FROM THE HOMEOWNER what accessories (surround, 16. Set-up remote control. screen, fan/blower, etc.) will be installed with 17. Verify operation and adjust aeration settings. this fireplace;... -
Page 11: Appliance Preparation
Existing Fireplace Preparation Gas Line Routing Combustible Mantels Plan the routing of the gas line before proceeding. Combustible mantel clearances must conform to those Utilize the existing hole for the gas line of the factory- required for the original solid-fuel fireplace into which built fireplace. -
Page 12: Window Removal
Appliance Preparation Window Removal The window is held in place by a spring-loaded lever on each side. 1. To remove the window, locate the levers on each side of the window towards the top. Using your finger, pull the lever towards you and unhook it from the window frame bracket. -
Page 13: Venting Installation
Appliance Preparation Venting Installation IMPORTANT: This appliance’s venting system is room sealed and therefore, does not require room air to be used in the combustion process. 1. Rough-in two 3” diameter vent liners into the existing chimney system from the roof. Be careful not to tear or damage the liners in the process. -
Page 14: Supply Gas Installation
Supply Gas Installation The gas supply inlet connection is a 1/2” NPT female. Pressure Test Points Gas shut-off valve supplied on the end of stainless The minimum supply pressure is given in the steel flexible connector. Flex connector is located on subsection Ratings of this manual—page 5. -
Page 15: Burner Removal And Reinstall
Burner Removal and Reinstall The ceramic panels can be installed without removing 2. Grab the burner as indicated and gently pull up the the burner. However, you can remove the burner for rear first and then the front. Be careful not to hook additional space if desired. -
Page 16: Ceramic Logs Installation
Ceramic Logs Installation Unpack the ceramic logs very carefully to avoid damaging them. Install the logs as shown below. Please note that the position of the logs is critical to insure proper performance of the appliance. When placing the base and middle logs, rotate them a little bit to anchor them into position. 1. - Page 17 Ceramic Logs Installation 4. Place the center base log locating its notch on the key in the ember bed as indicated. The darkened part of this log should be on the left side. 5. Place the right-hand base log locating its notch on the key in the ember bed as indicated. 6.
-
Page 18: Window Refitting
Ceramic Logs Installation 8. Place the right-hand cross log locating its notch on the key on the top of the rear log as indicated. Rest the front end of the log centered on top of the center base log. Ensure the logs do not cover the burner holes indicated here Window Refitting... -
Page 19: Remote Control Initial Set-Up
Remote Control Initial Set-up The receiver and the handset of the remote control 5. With a sharp object, press and hold the receiver’s system must be initially synchronized before the first reset button until you hear one short and one long use. -
Page 20: Operation Check & Aeration Settings Adjustment
Operation Check & Aeration Settings Adjustment Operation Check In a few unusual installations, the flame picture may be improved by adjusting the aeration. The need for Turn the fireplace flame up and down using the adjustment should be determined only by operating the remote control to confirm that the full range of inputs appliance with the ceramic logs and window installed. -
Page 21: Side Shrouds Installation
Side Shrouds Installation The side shrouds are required to install the front on Door hinge tabs the appliance. They are supplied with the engine. should face inwards Fit them to the appliance outer case as indicated (2 screws/side). Remote Control Handset Wall Holder Installation The remote control kit for this fireplace comes complete with a wall-mounted holder. -
Page 22: Owner's Information
Owner’s Information We have discussed this problem with ceramic glass WARNING manufacturers and they cannot give us a definitive HOT HEARTH! The hearth in front of the fireplace answer to this problem. Dealers have tried various cleaning products with varying results. The following becomes very hot when the fireplace heats. - Page 23 Owner’s Information Soot or dust can be brushed from the ceramic logs Batteries and firebox walls using a soft brush. Dust can also CAUTION be removed from the burner using a soft brush after DO NOT USE a screwdriver or other metallic removing the ceramic logs.
-
Page 24: Remote Control Operation
Owner’s Information Manual On/Off Switch In cases where you want to turn off your fireplace and cannot do it with the remote control handset (misplaced, lost, dead batteries, etc.) or if you need to replace the batteries in the battery box, you can turn off the appliance with the manual switch located on the left hand side of the appliance. - Page 25 Remote Control Operation Turning your fireplace ON IMPORTANT: When the pilot is lit, the valve motor turns automatically to maximum flame height. 1. Make sure that the MAN knob on the valve is in ON position. 2. Make sure that the switch on the valve is in the I position. 3.
-
Page 26: Flame Height
Remote Control Operation Operation Modes STANDBY MODE—Ignited pilot only. MAN MODE —Manual Mode. You can use this mode to adjust the flame height up or down. ☼ TEMP MODE —Daytime Temperature Mode (appliance must be in Standby mode; pilot ignited): The room temp temperature is measured and compared to the set temperature. - Page 27 Remote Control Operation Time To set the time, follow the steps below. 1. The display indicates °C/24-hour or °F/12-hour clock. To change from one to the other, press and hold both the OFF and buttons until the display changes. 2. To set the time, hold down both the buttons until the display flashes.
- Page 28 Remote Control Operation Timer It is possible to program two periods of time per day at which your fireplace will turn on and off automatically. ☼ For example, you can set your fireplace to turn on in the morning just before you get up (P1 P1 ☽...
-
Page 29: Options
795CFK—Circulating Fan Kit 787EBL—Enamel Black Liner Set 796ALP—Adjustable Leveling Platform 788FBL—Fluted Black Liner Set 797FSB—Framed Safety Screen Black 789VRL—Valor Red Brick Liner Set 1265WSK—Wall Switch Kit Conversion Kit Front (required) 785PGK—Conversion Kit to Propane Gas 790FTV—Floating Trim Kit Vintage Iron (2-1/2”) 785NGK—Conversion Kit to Natural Gas... -
Page 30: Lighting Instructions
Lighting Instructions FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life. A. This appliance has a pilot which must be lighted by hand or by remote control. Follow these instructions exactly. To save gas, turn the pilot off when not using the appliance for a prolonged period of time. -
Page 31: Wiring Diagram
Wiring Diagram Latching Solenoid Valve Optional Wall Switch Kit 1265WSK Connector Yellow Optional Fan Remote 795CFK Battery Box Control Module 4 AA Batteries GV60 Wiring Diagram... -
Page 32: Venting Table
Venting Table APPROVED DIRECT VENT SUPPLIERS FOR VALOR MODELS 739, 780, 785 & RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — HSDV4658-1313 — High Wind Co-axial 46DVA-VCH — — SV4CGV —... -
Page 33: Warranty
Warranty If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the first purchaser/user of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5. -
Page 34: Spare Parts
Ledgestone 786LSL Inlet brass connector 4000746 Enamel black 787EBL GV60 valve 4000873X Ceramic fluted black 788FBL Switch bracket 4002566 Valor red brick 789VRL 34” flex pipe 4002475 Top panel Solenoid 4002250 Ledgestone 4002368 Rear pipe assembly 4002486 Enamel black 4002374... - Page 35 Spare Parts Part Code Description Number Left side panel Ledgestone 4002365 Enamel black 4002371EB Ceramic fluted black 4002377 Valor red brick 4002382 Right side panel Ledgestone 4002366 Enamel black 4002372EB Ceramic fluted black 4002378 Valor red brick 4002383...
- Page 36 Spare Parts 3–7 32 – 38...
- Page 37 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualified dealer. Please circle where appropriate - ask your installer or your dealer if in doubt. The information provided will be used for customer records only.
- Page 38 Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfireplaces.com Were you given all documentation and manuals for your product? Thank you for choosing a Valor Product...
