Valor LEGEND G4 780IN (NG) Installation And Owner's Manual

Direct vent gas insert
Hide thumbs Also See for LEGEND G4 780IN (NG):

Advertisement

Installation and Owner's Manual
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury or loss of life.
Do not store or use gasoline or other
fl ammable vapors and liquids in the vicinity
of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS
• Do not try to light the appliance.
• Do not touch any electrical switch; do not
use any phone in your building.
• Immediately call your gas supplier from
a neighbor's phone. Follow the gas
supplier's instructions.
• If you cannot reach your gas supplier, call
the fi re department.
Installation and service must be performed
by a qualifi ed installer, service agency or the
gas supplier.
4002252-06
©2011, Miles Industries Ltd.
L
EGEND
Direct Vent Gas Insert
780IN (NG) & 780IP (LPG)
HOT GLASS WILL
CAUSE BURNS.
DO NOT TOUCH GLASS
UNTIL COOLED.
NEVER ALLOW CHILDREN
TO TOUCH GLASS.
Manufactured by
MILES INDUSTRIES LTD., British Columbia, Canada
www.valorfi replaces.com
G4
I NSTALLE R
Lea ve t his ma nua l
with t he applianc e.
C ON SU MER
Re tain t his manua l
for f uture ref e re nce.
Please read this manual BEFORE installing
and operating this appliance.
This appliance may be installed in an
after-market permanently located,
manufactured (mobile) home where not
prohibited by local codes.
This appliance is only for use with the type
of gas indicated on the rating plate. This
appliance is not convertible for use with
other gases, unless a certifi ed kit is used.
This appliance is a domestic room-heating
appliance. It must not be used for any other
purposes such as drying clothes, etc.
This appliance is suitable for installation in a
bedroom or bed sitting room.
Massachusetts: The piping and fi nal
gas connection must be performed by a
licensed plumber or gas fi tter in the State of
Massachusetts.
Ce guide est disponible en français sur demande.
Patent Pending

Advertisement

Table of Contents
loading

Summary of Contents for Valor LEGEND G4 780IN (NG)

  • Page 1 fi tter in the State of by a qualifi ed installer, service agency or the Massachusetts. gas supplier. Ce guide est disponible en français sur demande. Manufactured by MILES INDUSTRIES LTD., British Columbia, Canada www.valorfi replaces.com 4002252-06 ©2011, Miles Industries Ltd.
  • Page 2: The Fireplace

    For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Each Valor fi replace is fully tested during the production process for your safety and comfort.
  • Page 3: Safety And Your Fireplace

    Child Safety Precautions and Recommendations, • A physical barrier is strongly recommended if there are young Parts of your Valor Fireplace become • children, or at-risk individuals in the extremely hot while in operation. house. Install an approved after- The glass viewing window •...
  • Page 4: Table Of Contents

    Table of Content Safety and Your Fireplace ................3 Safety and Warning Information..............5 Specifi cations ....................6 ◊ Overview ......................7 Dimensions ....................8 Cavity ......................8 ◊ Clearances ......................9 Venting ......................10 Installation Planning ..................11 Existing Fireplace Preparation ..............11 Appliance Preparation .................12 ◊ Supply Gas Installation ................15 Ceramic Panels Installation ................17 Ceramic Logs Installation ................18 Ceramic Rocks Installation .................21...
  • Page 5: Safety And Warning Information

    Safety and Warning Information OWNER’S INFO READ and UNDERSTAND all instructions carefully This unit MUST be used with a vent system as before starting the installation. FAILURE TO FOLLOW described in this installation manual. NO OTHER vent these installation instructions may result in possible fi re system or components MAY BE USED.
  • Page 6: Specifi Cations

    Safety and Warning Information OWNER’S INFO Operating your fi replace for the fi rst time. When It is also possible that these vapors could set off any operating your new fi replace for the fi rst time, some smoke detection alarms in the immediate vicinity. vapors may be released due to the burning of curing These vapors are quite normal on new appliances.
  • Page 7: Overview

    Overview INSTALLATION This appliance may ONLY be installed in an existing unaltered, functioning solid-fuel burning fi replace with a working fl ue and constructed of non-combustible material. DO NOT install into combustible construction. This appliance is NOT APPROVED for installation with a zero clearance kit. WARNING Chimney Terminal Cap Some materials or items, although...
  • Page 8: Dimensions

    Dimensions INSTALLATION 33” (838 mm) 24” (610 mm) 6’ (1.9 m) Fan power cord 3” (76 mm) Optional fan 3” 3” 15” (76 mm) (76 mm) (381 mm) 15” 4” Trim (381 mm) (102 mm) (sold separately) 10” Gas line approx. 24“ (610 mm) of flex protruding from (254 mm) sheet metal box...
  • Page 9: Clearances

    Clearances INSTALLATION WARNING Some materials or items, although safe, may discolor, shrink, warp, crack, peel, Some materials or items, although safe, may discolor, shrink, warp, crack, peel, and so on because of the heat produced by the fi replace. Avoid placing candles, and so on because of the heat produced by the fi...
  • Page 10: Venting

    Venting INSTALLATION Typical Vent Installation See list of approved Venting Accessories on page 38 of this manual. NOTE: Flexible co-linear vent pipes may only be installed into existing non-combustible solid-fuel burning fi replaces and chimneys. Terminal Cap Vent Location The vent terminal must be located through the roof.
  • Page 11: Installation Planning

    Installation Planning INSTALLATION 14. Install ceramic panels and fuel bed. Installer—READ THIS FIRST 15. Refi t window. 1. YOU NEED TO KNOW FROM THE 16. Set-up remote control. HOMEOWNER what accessories (surround, screen, fan/blower, etc.) will be installed with 17. Verify operation and adjust aeration settings. this fi...
  • Page 12: Appliance Preparation

    Existing Fireplace Preparation INSTALLATION Gas Line Routing Combustible Mantels Plan the routing of the gas line before proceeding. Combustible mantel clearances must conform to those Utilize the existing hole for the gas line of the factory- required for the original solid-fuel fi replace into which built fi...
  • Page 13 Appliance Preparation INSTALLATION Window Removal The window is held in place by a spring-loaded lever on each side. 1. To remove the window, locate the levers on each side of the window towards the top. Using your fi nger, pull the lever towards you and unhook it from the window frame bracket.
  • Page 14 Appliance Preparation INSTALLATION Venting Installation IMPORTANT: This appliance’s venting system is room sealed and therefore, does not require room air to be used in the combustion process. 1. Rough-in two 3” diameter vent liners into the existing chimney system from the roof. Be careful not to tear or damage the liners in the process.
  • Page 15: Supply Gas Installation

    Supply Gas Installation INSTALLATION The gas supply inlet connection is a 1/2” NPT female. Pressure Test Points Gas shut-off valve supplied on the end of stainless The minimum supply pressure is given in the steel fl exible connector. Flex connector is located on section Specifi...
  • Page 16 Supply Gas Installation INSTALLATION Use common elbow and fi ttings (not Alternate Inlet Connection supplied) to redirect the position of In cases where local codes do not permit the fl ex the fl ex connector. NOTE: the fl ex connector to be used inside the appliance case, connector bend radius must be no reconnect the fl...
  • Page 17: Ceramic Panels Installation

    Ceramic Panels Installation INSTALLATION The following guidelines apply for all brick liners. 5. Rotate the anchor up and out of the way and slide the left hand side panel against the fi rebox side. 1. Remove the rear log support (3 screws). Rotate the anchor back down to hold the panel.
  • Page 18: Ceramic Logs Installation

    Ceramic Panels Installation INSTALLATION 11. With logs only: Install the front bricks in front of the 9. Reinstall the front brick support. burner. 10. Reinstall the rear log support (3 screws). Its rear 12. With logs only: Slide the cast iron grate in the edge rests on the rear brick support ledge.
  • Page 19 Ceramic Logs Installation INSTALLATION 2. Place the black glass piece on top of the burner and 4. Place the right front log with its left end fl at on the move it forward to rest in the grooved recess of the glass.
  • Page 20 Ceramic Logs Installation INSTALLATION 6. Identify the top right log. It is the longest of the two 7. Place the top left log’s wider end on the peg of the remaining logs. Place its wider end on the front right front left log and rest its narrow end in the notch on log’s peg and rest its narrow end in the notch on the the rear log.
  • Page 21: Ceramic Rocks Installation

    Ceramic Rocks Installation INSTALLATION For ceramic logs, see previous section. Unpack the ceramic rocks very carefully to avoid damaging them. Install the rocks as shown. Please note that the position of some of the rocks identifi ed in the following instructions is critical to ensure proper performance of the appliance.
  • Page 22 Ceramic Rocks Installation INSTALLATION 4. Each rock is embossed 8. Identify the rocks 7, 9, 11 and 14. These rocks underneath with a number have one hole underneath and fi t on the peg of and an arrow indicating the rocks 6, 8, 10 and 13 respectively. Install these its position.
  • Page 23: Window Refi Tting

    Ceramic Rocks Installation INSTALLATION 11. Optional: Lay the twigs on the rocks. They can be IMPORTANT: The rocks of the top row (14, 11, 9 placed as suggested below or elsewhere on the and 7) overhang slightly over the burner. rocks as long as they do not block the pilot fl...
  • Page 24: Remote Control Initial Set-Up

    Remote Control Initial Set-up INSTALLATION The receiver and the handset of the remote control 5. With a sharp object, press and hold the receiver’s system must be initially synchronized before the fi rst reset button until you hear one short and one long use.
  • Page 25: Operation Check & Aeration Settings Adjustment

    Operation Check & Aeration Settings Adjustment INSTALLATION In a few unusual installations, the fl ame picture may Operation Check be improved by adjusting the aeration. The need for Turn the fi replace fl ame up and down using the adjustment should be determined only by operating the remote control to confi...
  • Page 26: Remote Control Handset Wall Holder Installation

    Remote Control Handset Wall Holder Installation OWNER’S INFO The remote control kit for this fi replace comes complete with a wall-mounted holder. Alternative 2 Alternative 3 Packing Contents: This holder is not required in all installations 1 Wall Bracket A but is provided as an optional feature for 2 Screws B those customers who wish to mount the...
  • Page 27 Owner’s Information OWNER’S INFO Do not clean the glass while it is hot. Always Cleaning securely replace the window before lighting. If broken, WARNING the glass pane may only be replaced as a complete window unit as supplied by the manufacturer. DO NOT TOUCH THE GLASS WHILE IT IS HOT! DO NOT TOUCH THE GLASS WHILE IT IS HOT! Let the fi...
  • Page 28 Owner’s Information OWNER’S INFO The appliance area must always be kept clear and Checks free from combustible materials, gasoline and other A periodic check of the pilot and burner fl ames should fl ammable vapors and liquids. be made. Check after the fi re has been on for at least Inspect the vent terminal outdoors regularly to make 30 minutes.
  • Page 29 Owner’s Information OWNER’S INFO 4. Replace the 4 AA batteries. (including pilot) How to Turn Your Fireplace OFF 5. Replace the cover and screw in place. Familiarize yourself with each of these methods before 6. Reconnect the battery box. operating your fi replace. 7.
  • Page 30: Remote Control Operation

    Remote Control Operation OWNER’S INFO NOTE: Before using the remote control system for IMPORTANT: BEFORE YOU BEGIN, please note that the fi rst time, the receiver and the handset must be on this system, the settings of time, temperature and synchronized.
  • Page 31 Remote Control Operation OWNER’S INFO • Press and hold (small fl ame) MODES OF OPERATION button to decrease fl ame height or • Briefl y pressing the SET button to set the appliance at pilot fl ame. changes the mode of operation in •...
  • Page 32 Remote Control Operation OWNER’S INFO • SETTING THE ON / OFF TEMPERATURES - Nighttime Setback T E M P Temperature Mode (Appliance must be in standby mode; pilot SETTING THE “DAYTIME” TEMPERATURE ignited) - The room temperature (sun), Default Settings: 23ºC / 74ºF TEMP is measured and compared to the...
  • Page 33 Remote Control Operation OWNER’S INFO SETTING THE “NIGHTTIME SETBACK” SETTING PROGRAM TIMERS TEMPERATURE • You can program two periods of time between 12:00 (moon), Default Settings: “ ” (OFF) T E M P am and 11:50 pm in each 24-hour cycle. •...
  • Page 34 Remote Control Operation OWNER’S INFO SETTING P1 OFF TIME SETTING P2 ON TIME • Briefl y press SET to scroll to TIMER mode • Briefl y press SET button to scroll (sun) while the time fl ashes. to TIMER (moon) while the •...
  • Page 35: Options

    786LSL—Ledgestone Liner Set 795CFK—Circulating Fan Kit 787EBL—Enamel Black Liner Set 796ALP—Adjustable Leveling Platform 788FBL—Fluted Black Liner Set 797FSB—Framed Safety Screen Black 789VRL—Valor Red Brick Liner Set 1265WSK—Wall Switch Kit Conversion Kit Fuel Bed (required) 780PGK—Conversion Kit to Propane Gas 781RSK—Rock Set 780NGK—Conversion Kit to Natural Gas...
  • Page 36: Lighting Instructions

    Lighting Instructions OWNER’S INFO FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING : If you do not follow these instructions exactly a re or ex losion ay result causin ro erty da a e ersonal in ury or loss of life A.
  • Page 37: Wiring Diagram

    Wiring Diagram INSTALLATION Optional Wall Switch Kit 1265WSK Connector Yellow Optional Fan Remote Control Battery Box Module 4 AA Batteries GV60 MAX Wiring Diagram...
  • Page 38: Approved Venting Components

    Approved Venting Components INSTALLATION Approved Direct Vent Suppliers for Valor Models 739, 780, 785 and RF24DV Venting Parts Code / availability by Manufacturer Venting Parts Description 4DVC Standard Co-axial 46DVA-VC 4DT-VC TM-4VT — HSDV4658-1313 — 4DH-1313 High Wind Co-axial 46DVA-VCH —...
  • Page 39: Warranty

    Warranty OWNER’S INFO If you have a problem with this unit, please contact your dealer or supplier immediately. Under no circumstances should you attempt to service the unit in any way by yourself. The warranties in paragraphs 1 and 2 are provided only to the fi rst purchaser/user of this unit, are not transferable and are subject to the conditions and limitations in paragraphs 3, 4 and 5.
  • Page 40: Spare Parts

    Spare Parts OWNER’S INFO Part Part Code Description Code Description Number Number Exhaust slide assembly 4002287 Valve 4000873X Exhaust slide gasket 4000176 34” fl ex pipe with shut-off valve 4002475 Restrictor enclosure 4002330 Air shutter slider NG 4002345 Metal strip 4002329 Air shutter cover NG 4002346...
  • Page 41 Ceramic platform—sand 4002439 Platform support assembly 4002663 Liner panels—complete set Ledgestone 786LSL Enamel black 787EBL Ceramic fl uted black 788FBL Valor red brick 789VRL Top panel Ledgestone 4002368 Enamel black 4002374 Ceramic fl uted black 4002374 Valor red brick 4002385...
  • Page 42 Spare Parts OWNER’S INFO 3 - 7 56 - 57 71 72 27 - 32 16 - 23...
  • Page 43 Thank You ... For purchasing a Valor by Miles Industries. Your new radiant gas heater is a technical appliance that must be installed by a qualifi ed dealer. Please circle where appropriate - ask your installer or your dealer if in doubt. The information provided will be used for customer records only.
  • Page 44 Tape Shut Fold here Postage needed Miles Industries Ltd. 190 - 2255 Dollarton Highway North Vancouver, BC V7H 3B1 Canada Online Warranty registration at www.valorfi replaces.com Thank you for choosing a Valor Product...
