1. Connect the VoIP Ports 0/1 and 0/1 to your network (see
Note Ethernet ports (ETH 0/0 & 0/1), and SMS ports (SMS-0/0 & 0/1) are not
used when connecting VoIP.
1. Connect the SN10200A to the PSTN, using one of the following options:
SCSI Interface (T1/E1), (patch panel provided)
–
Dual BNC (DS3)
–
Optical Interface (OC3/STM-1)
–
4.1 SCSI (T1/E1)
T1/E1
SCSI connectors
4.2 Dual BNC (DS3)
DS3
Dual BNC connectors
Figure 4.
SmartNode 10200A Series Quick Start Guide

3.0 Connecting to the VoIP Network

Figure 2.

4.0 Connecting to the PSTN Network

Figure 3.
Connecting to the PSTN via Dual BNC connectors
ETH VOIP
0 1 0 1
VoIP Ports 1–2
Connecting the VoIP ports
ETH VOIP
0 1 0 1
Connecting to the PSTN via SCSI
ETH
VOIP
0 1 0 1
figure
MGMT0
TMS
0 1
MGMT0
TMS
0 1
MGMT0
TMS
0 1
2).
5
