xConfiguration Conference MaxReceiveCallRate

Define the maximum receive bit rate to be used when placing or receiving calls. Note that this
is the maximum bit rate for each individual call; use the Conference MaxTotalReceiveCallRate
setting to set the aggregated maximum for all simultaneous active calls.
Requires user role: ADMIN
Default value: 6000
USAGE:
xConfiguration Conference MaxReceiveCallRate:
where
MaxReceiveCallRate
: Integer (64..6000)
The maximum receive call rate (kbps).

xConfiguration Conference MaxTransmitCallRate

Define the maximum transmit bit rate to be used when placing or receiving calls. Note that this
is the maximum bit rate for each individual call; use the Conference MaxTotalTransmitCallRate
setting to set the aggregated maximum for all simultaneous active calls.
Requires user role: ADMIN
Default value: 6000
USAGE:
xConfiguration Conference MaxTransmitCallRate:
where
MaxTransmitCallRate
: Integer (64..6000)
The maximum transmitt call rate (kbps).
SX20 Codec API Reference Guide CE8.1, APRIL 2016.
D15316.03
About the API xConfiguration xConfiguration
MaxReceiveCallRate
MaxTransmitCallRate
xCommand

xConfiguration Conference MaxTotalReceiveCallRate

This configuration applies when using a video system's built-in MultiSite feature (optional) to
host a multipoint video conference.
Define the maximum overall receive bit rate allowed. The bit rate will be divided fairly among
all active calls at any time. This means that the individual calls will be up-speeded or down-
speeded as appropriate when someone leaves or enters a multipoint conference, or when a call
is put on hold (suspended) or resumed.
The maximum receive bit rate for each individual call is defined in the Conference
MaxReceiveCallRate setting.
Requires user role: ADMIN
Default value: 6000
USAGE:
xConfiguration Conference MaxTotalReceiveCallRate:
where
MaxTotalReceiveCallRate
: Integer (64..6000)
The maximum receive call rate (kbps).

xConfiguration Conference MaxTotalTransmitCallRate

This configuration applies when using a video system's built-in MultiSite feature (optional) to
host a multipoint video conference.
Define the maximum overall transmit bit rate allowed. The bit rate will be divided fairly among
all active calls at any time. This means that the individual calls will be up-speeded or down-
speeded as appropriate when someone leaves or enters a multipoint conference, or when a call
is put on hold (suspended) or resumed.
The maximum transmit bit rate for each individual call is defined in the Conference
MaxTransmitCallRate setting.
Requires user role: ADMIN
Default value: 6000
USAGE:
xConfiguration Conference MaxTotalTransmitCallRate:
where
MaxTotalTransmitCallRate
: Integer (64..6000)
The maximum transmit call rate (kbps).
