Table 29: Replaceable Parts List, 4-Channel Models - Tektronix TDS2022C Service Manual

Table 29: Replaceable parts list, 4-channel models

Figure
and Serial
index Tektronix no.
no. part no. effective
8-2
-1 850-0157-00
-2 366-0863-00
-3 366-0862-00
-4 335-2318-00
335-2319-00
335-2320-00
335-2321-00
335-2322-00
335-2323-00
335-2324-00
335-2325-00
335-2326-00
335-2327-00
-5 260-2905-70
-6 211-1272-00
-7 870-0190-02
-8 441-2455-00
-9 870-0874-00
C030000
870-0875-00 C030000
870-0876-00 C030000
-10 210-1039-00
-11 220-0265-00
-12 131-6417-00
-13 131-6521-00
-14 220-0297-00
-15 210-1610-00
-16 441-2712-00
-17 850-0115–70
-18 348-1525-00
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
Serial
no.
discont'd Qty. Name and description
4-CHANNEL MODELS
1
FRONT CASE ASSY; COVER, W/FEET, TDS2004C, TDS2014C, TDS2024C
1 ASSEMBLY, KNOB; 0.685 DIAMETER
1 ASSEMBLY, KNOB; 0.470 DIAMETER
1
MARKER, IDENTIFICATION 4-CH LANGUAGE, FRENCH
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, ITALIAN
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, GERMAN
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, SPANISH
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, JAPANESE
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, PORTUGUESE
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, SIMPLIFIED CHINESE
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, TRADITIONAL CHINESE
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, KOREAN
1 MARKER, IDENTIFICATION 4-CH LANGUAGE, RUSSIAN
1 SWITCH, KEYPAD; ELASTOMERIC, FRONT PANEL, 4 CH COLOR, BONDED
9
SCREW, MACHINE; 6-32 X 0.250, PNH, STL, ZNPL, T- 15 TORX DR
1 CIRCUIT BD ASSY; FRONT PANEL BOARD 4-CH, 389-3836-00 WIRED
1 CHASSIS ASSY; 4 CHANNEL
1
CIRCUIT BD ASSY; MAIN, 4-CH, 70 MHZ, TESTED & CONFIGURED, COLOR,
389-4334-00 WIRED; TDS2004C
1 CIRCUIT BD ASSY; MAIN, 4-CH, 100 MHZ, TESTED & CONFIGURED, COLOR,
389-4334-00 WIRED; TDS2014C
1 CIRCUIT BD ASSY; MAIN, 4-CH, 200 MHZ, TESTED & CONFIGURED, COLOR,
389-4334-00 WIRED; TDS2024C
5 WASHER, LOCK; 0.521 ID, INT, 0.025 THK, STEEL, ZINC FINISH
5 NUT, PLAIN, HEX; 0.5-28 X 0.625 HEX, BRS, NKL PL
1 CONTACT, ELEC; GROUNDING, 0.600 L X 0.250 W X 0.220 D, ELECTROLESS NICKEL
PLATE
1 CONTACT, ELEC; EMI, CLIP-ON, 0.38 L X 0.460 W (2 CONTACTS) X 0.45 HIGH,
ELECTROLESS NICKEL PLATE
4 LCD, NUT, M4
4 LCD, STANDARD SPRING WASHER, M4
2 SHIELD, GUARD/VIBRATION DAMPER
1 DISPLAY ASSY; COLOR
2 FOOT; FRONT, SANTOPRENE, BLACK, 64 DEROMETER, TEXTURED
Replaceable Parts
93
