Specifications
Interfaces and Output Ports Specifications
Table 5: Interfaces and output ports specifications
Characteristic Description
USB Device USB 2.0 Full Speed device. 12 Mb/second maximum. Supports PICTBRIDGE compatibility and provides
USB-TMC communications with Tektronix extensions.
Standard
USB Host USB 2.0 Full Speed host. 12 Mb/sec maximum. Supports USB Mass Storage Class. Bulk Only Subclass
only. Provides full 0.5 A of 5 V.
Standard
USB Host Current Provides full 0.5 A of 5 V.
Standard
GPIB Interface GPIB access via TEK-USB-488 accessory.
Probe Compensator, Output voltage: 5.0 V ±10% into 1 MΩ load.
Output Voltage and
Frequency: 1 kHz
Frequency, typical

Data Handling Characteristics

Table 6: Data handling characteristics

Characteristic Description
Retention of Front Front panel settings are stored periodically in memory. The settings are not lost when the instrument is
Panel Settings turned off or if there is a power failure.
Stored Waveforms and Two Channel 1, Channel 2, or Math waveforms can be stored in nonvolatile waveform memory A or
Multiple Front Panel B. One, both, or neither of A or B waveform memories can be displayed. For the TDS20X4C, four
Settings waveforms, A, B, C, D, or Math can be stored. Ten user setups of the current instrument settings can be
saved and restored from nonvolatile memory. Additional storage is available when an appropriate mass
storage device is connected via USB.

Power Distribution System

Table 7: Power distribution system

Characteristic
Power Consumption
Source Voltage
Source Frequency
Fuse Rating
14
Description
Less than 30 W at 85 to 275 V
Full Range: 100 to 240 V
ACRMS
360 Hz to 440 Hz from 100 V
45 Hz to 66 Hz from 100 V
AC
3.15 Amps, T rating, 250 V; IEC and UL approved.
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
input.
AC
± 10%, Installation Category II (Covers range of 90 to 264 V
to 120 V .
AC AC
to 240 V .
AC
AC
