Exterior Inspection

Table 16: External inspection checklist

Item
Front and rear case
Front-panel knobs
Connectors
Carrying handle, and cabinet feet
Accessories

Interior Inspection

TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
If the display is very dirty, moisten the wipe with distilled water or a 75%
isopropyl alcohol solution and gently rub the display surface. Avoid using excess
force or you may damage the plastic display surface.
Inspect the outside of the oscilloscope for damage, wear, and missing part. (See
Table 16.) Immediately repair defects that could cause personal injury or lead
to further damage to the oscilloscope.
Inspect for
Cracks, scratches, deformations, damaged
hardware
Missing, damaged, or loose knobs
Broken shells, cracked insulation, and
deformed contacts. Dirt in connectors
Correct operation
Missing items or parts of items, bent pins,
broken or frayed cables, and damaged
connectors
To access the inside of the oscilloscope for inspection and cleaning, refer to the
Removal Procedures in this section.
Inspect the internal portions of the oscilloscope for damage and wear. (See
Table 17.) Repair any defects immediately.
If any circuit board is repaired or replaced, check the table to see if it is necessary
to adjust the oscilloscope. (See Table 17.)
CAUTION.
To prevent damage from electrical arcing, make sure that circuit
boards and components are dry before applying power to the oscilloscope.
Repair action
Repair or replace defective module
Repair or replace missing or defective knobs
Repair or replace defective modules. Clear
or wash out dirt.
Repair or replace defective module
Repair or replace damaged or missing
items, frayed cables, and defective modules
Maintenance
