Maintenance

Preventing ESD

Inspection and Cleaning

TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
This chapter contains the information needed to do periodic and corrective
maintenance on the oscilloscope, as well as repackaging instructions to use if you
need to return the oscilloscope to Tektronix for service.
Before servicing this product, read the Safety Summary and Introduction at the
front of the manual and the electrostatic discharge (ESD) information below.
CAUTION.
Static discharge can damage any semiconductor component in this
oscilloscope.
When performing any service which requires internal access to the oscilloscope,
adhere to the following precautions. These precautions help you avoid damaging
internal modules and their components due to electrostatic discharge (ESD):
Minimize handling of static-sensitive modules.
Transport and store static-sensitive modules in their static protected containers
or on a metal rail. Label any package that contains static-sensitive modules.
Discharge the static voltage from your body by wearing a grounded antistatic
wrist strap while handling these modules.
Service static-sensitive modules only at static-free workstations. Do not allow
anything capable of generating or holding a static charge on the workstation
surface.
Handle circuit boards by the edges when possible.
Do not slide the modules over any surface.
Avoid handling modules in areas that have a floor or work-surface covering
capable of generating a static charge.
Inspection and cleaning are done as preventive maintenance. Preventive
maintenance, when done regularly, can prevent oscilloscope malfunction and
enhance its reliability.
Preventive maintenance consists of visually inspecting and cleaning the
oscilloscope, and using general care when operating it. How often you do
maintenance depends on the severity of the environment in which you use the
oscilloscope. A good time to perform preventive maintenance is just before
adjustment of the oscilloscope.
49
