Table 1: Signal acquisition system characteristics (cont.)
Characteristic
Upper-Frequency Limit,
20 MHz Bandwidth
Limited, typical
Lower- Frequency Limit,
AC Coupled
Rise Time, typical
Peak Detect Mode Pulse
Response
Vertical Position Ranges
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
Description
This is the upper frequency for Analog Bandwidth when the instrument has 20 MHz bandwidth limiting
turned on.
20 MHz
Bandwidth of all trigger paths are similarly limited, except the External Trigger, which is not affected
by BW Limit function. Each channel is separately limited, allowing different bandwidths on different
channels of the same instrument.
This is the lower frequency for Analog Bandwidth when the instrument is AC-coupled
≤ 10 Hz.
<1 Hz when 10X, passive probes are used.
Model
TDS2022C, TDS2024C
TDS2012C, TDS2014C
TDS2002C, TDS2004C
TDS2001C
TDS1012C-EDU
TDS1002C-EDU
TDS1001C-EDU
Rise time is generally calculated from the following formula: Rise time in ns = 350 / Bandwidth in MHz
This is the capability of the instrument to capture single event pulses using the Peak Detect Acquisition
Mode.
The minimum single pulse widths for guaranteed 50% or greater amplitude capture are as follows:
Model
TDS1002C-EDU
TDS1012C-EDU
TDS2002C
TDS2004C
TDS2012C
TDS2014C
TDS2022C
TDS2024C
TDS1001C-EDU
TDS2001C
These are the ranges of the user-settable input offset voltage.
Volts/Div Setting
2 mV/div to 200 mV/div
> 200 mV/div to 5 V/div
Expected full bandwidth rise time
2.1 ns
3.5 ns
5.0 ns
7.0 ns
3.5 ns
5.8 ns
8.8 ns
Sec/Div Setting
50 sec/div to 5 μS/div
50 sec/div to 5 μS/div
Position Range
± 1.8 V
± 45 V
Specifications
Minimum Pulse Width
12 ns
13 ns
