Maintenance
Removal and Installation Procedures
Summary of Procedures
54
WARNING.
Only qualified personnel should perform service procedures. Before
doing this or any other procedure in this manual, read the General Safety
Summary and Service Safety Summary found at the beginning of this manual. To
prevent damage to electrical components, refer to Preventing ESD. (See page 49,
Preventing ESD.)
Always disconnect the power cord before disassembling any part of the
oscilloscope.
Refer to the module locator drawings to find the modules that you want to remove
or install. (See Figure 5 on page 55.) (See Figure 6.)
Refer to the Inspection and Cleaning procedure if you are disassembling the
instrument for cleaning. (See page 49, Inspection and Cleaning.)
Refer to the Replaceable Parts List for a list of all replaceable modules and their
part numbers.
Refer to the Exploded View Diagrams for each procedure, as indicated in the table.
Complete disassembly is best achieved by following the procedures in the order
given in the following table:
Procedure
Rear Feet
Flip Feet
Front-Panel Knobs
Rear Case
Front Feet
Power Supply Module
Internal Assembly
Front-Panel Cable
Main Board Module
Display Module
Front-Panel Module
Keypad
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
Begins on page
(See page 56, Rear Feet.)
(See page 57, Flip Feet.)
(See page 57, Front-Panel Knobs.)
(See page 58, Rear Case.)
(See page 59, Front Feet.)
(See page 60, Power Supply Module.)
(See page 61, Internal Assembly.)
(See page 62, Front-Panel Cable.)
(See page 63, Main Board Module (Serial number C030000
or later).)
(See page 66, Display Module.)
(See page 67, Front-Panel Module.)
(See page 68, Keypad.)
