Performance Verification

Required Equipment

Table 12: Performance verification
Description
DC Voltage Source
Leveled Sine Wave Generator
Time Mark Generator
50Ω BNC Cable
50Ω BNC Cable
50Ω Feedthrough Termination
Dual Banana to BNC Adapter
BNC T Adapter
Splitter, Power
Adapter (four required)
Adapter
Leads, 3 Black
Leads, 2 Red
TDS2000C and TDS1000C-EDU Series Oscilloscope Service Manual
This chapter contains performance verification procedures for the specifications
marked with the check mark. The following equipment, or a suitable equivalent,
is required to complete these procedures.
Minimum requirements
17.5 mV to 7 V, ±0.5% accuracy
50 kHz and 200 MHz, ±3% amplitude accuracy
10 ms period, ±10 ppm accuracy
BNC male to BNC male, ≈ 1 m (36 in) long
BNC male to BNC male, ≈ 25 cm (10 in) long
BNC male and female connectors
Banana plugs to BNC female
BNC male to dual BNC female connectors
Frequency range: DC to 4 GHz.
Tracking: >2.0%
Male N-to-female BNC
Female N-to-male BNC
Stacking Banana Plug Patch Cord, ≈ 45 cm
(18 in) long
Stacking Banana Plug Patch Cord, ≈ 45 cm
(18 in) long
Examples
Wavetek 9100 Universal Calibration
System with Oscilloscope Calibration
Module (Option 250)
Fluke 5500A Multi-product Calibrator with
Oscilloscope Calibration Option (Option
5500A-SC)
Tektronix part number 012-0482-XX
Tektronix part number 012-0208-XX
Tektronix part number 011-0049-XX
Tektronix part number 103-0090-XX
Tektronix part number 103-0030-XX
Tektronix part number 015-0565-XX
Tektronix part number 103-045-XX
Tektronix part number 103-0058-XX
Pomona #B-18-0
Pomona #B-18-2
27
