ATTENTION: The 108293 Bench Top does not include legs as shown below. Legs, bracing, and fittings are
included with the 108293S Bench System only. Installation of the PolyMax® panels is the same for both.
Gather four (4) PolyMax® (#HA2217) panels for the bench top.
Set the PolyMax® panels in place as shown and square them on the frame. Using the mounting holes in
the panels, secure them to the frame using 117413 flat screws. Do not overtighten. Screws should be snug.
Verify that flat screw tops are flush with the PolyMax® panel surface, or below.
NOTE: Pilot holes may need to be pre-drilled into the bench frame for flat screw connection.
NOTE: White dashed lines
show the seams between the
separate panels.
Slide panels in to interlock.
Revision date: 10.26.21
GREENHOUSE BENCH KITS
Flat screws
Align panels
with frame
before attaching
with Tek screws.
