FarmTek 104940 Quick Start Manual

104940 Row Cover Kit
Thank you for purchasing the 104940 Row Cover Kit. Assembly is quick and easy. Follow the procedure as shown.
You will need an adjustable tape measure and a hammer to complete the steps.
Gather the parts:
• 104155 rafters (plain and swaged pipes)
• CC6211 fabric clips
• CC4432 fabric staples
• Cover film
Frame Assembly Procedure
1. Select two (2) pipes (one with a swaged end and one with
two plain ends) to assemble a rafter. Slide the swaged
portion of one pipe into the plain end of the other pipe as
shown. Repeat to assemble all rafters.
2. With the rafter pipes seated at the joint, determine how
much of the rafter leg you want to set into the ground and
mark this on the rafter ends. This helps set all rafters at
the same depth. Soil conditions will determine depth.
3. Layout the site and frame position using the diagram
below. All dimensions are on-center (oc).
4. With assistance, carefully stand the first end rafter and
push each end into the ground. Use the marks on the
rafter ends to gauge depth.
5. Set the remaining rafters in the ground as shown below
and continue with the cover film installation procedure.
NOTE: Purlins (additional purchase
required) can help stabilize a frame.
Please call customer service at
1-800-245-9881 for additional
information. Purlins are not
included with the 104940 kit.
End Rafter
Mark here.
Revision date: 03.23.11
3' more or less –
depends on how
much rafter is
pushed into the
ground.
F a r m T e k ®
STEP 1: Connect rafter pipes.
If you have any questions, please call
us toll free at 1-800-FARMTEK.
