- Page 1 LAWN AND GARDEN 108681 Rolling Work Seat 12855 ©2012 FarmTek STK# DIMENSIONS ® All Rights Reserved. Reproduction 108681 14” W x 31” L x 18” H is prohibited without permission. Revision date: 05.01.12...
-
Page 2: Required Tools
LAWN AND GARDEN REQUIRED TOOLS The following list identifies the main tools needed for assembly. • Flat head screwdriver • Phillips head screwdriver • Metric wrench or socket set (or an small, adjustable wrench) YOU MUST READ THIS DOCUMENT BEFORE YOU BEGIN TO ASSEMBLE THE WORK SEAT. - Page 3 LAWN AND GARDEN PICTORIAL PARTS LIST The following photos will help you identify the different parts. 10x15mm Flat Head Bolts (4) 6x12mm Pan Head Bolts (4) Cotter Pins (5) 10mm Washers (4) 12mm Washers (4) 10mm Nuts (4) 12mm Nuts (4) Flat Plates (2) 12x32mm Flat Washers (8) Large Washer (1)
- Page 4 LAWN AND GARDEN 108681 Rolling Work Seat ASSEMBLY INSTRUCTIONS Slide the axles into the frame. Turn the frame upside down and attach the tool tray using the two (2) flat plates and 6x12mm pan head bolts, washers, and nuts. Do not tighten the bolts at this time.
-
Page 5: Maintenance
LAWN AND GARDEN ASSEMBLY INSTRUCTIONS (continued) Insert a cotter pin into each pre-drilled hole on the Thread the seat assembly onto the frame in a axle. Using a pliers, spread the ends of the cotter pins clockwise motion until the threaded post can be seen and wrap ends tightly around the axles to secure the from under the work seat.
