REVEX
1PH from 30A to 40A
16
Electronic boards
16.1 Supply the Electronic Board
The REVEX thyristor unit, to work, requires a voltage supply for the electronic boards of 24Vdc 500 mA on
terminal M3 (1-; 2+).
Warning: Before connecting or disconnecting the unit check that power and control cables
are isolated from voltage sources.
59
User's manual
