REVEX
1PH from 30A to 40A
Parameter Name
Alm Out Fn
Option
Heater Break
Short Circuit
Current Limit
Therm
Communication
DEFAULT
Alarm Bitwise is allowed
Parameter Name
IL SP Src
Choose how the current limit is set
DEFAULT: Local / Comms
Parameter Name
Start Disp
Choose which parameter is displayed on the home
page at power-up
Description
Choose for which conditions the digital output
indicates alarm. The output always indicate an
alarm when the heat sink is over temperature. The
digital output is energized for normal operating
condition and de-energized when the power
controller is off or when there is an alarm.
Note!: The power controller monitors for heater
break or short circuit condition only when included
in the option selected for Alarm Output Function
Heater Break
Short circuit
Current Limit
SCR is over temperature
Communication watchdog error
Description
Option
Local / Comms
Set point set via keypad or communication
Analog In 2
Set point set via analog input
Description
Option
Current
Volts Out
Power
DEFAULT: Voltage
Description
Description
Value
0
1
2
1
36
User's manual
Modbus
Default
Address
1 34
Modbus
Default
Address
16 14, bit 4
Value
16
0
16
Modbus
Default
Address
1 60
Par.
Type
Read
Write
Bit
0
1
2
3
4
None
Par.
Type
Read
Write
Par.
Type
Read
Write
