REVEX
1PH from 30A to 40A
9.4.6 Monitoring Menu
This section describes each item on the monitoring menu. Use this menu to view the states of digital input,
values of analog input and information about the power controller such as serial number and software version.
The password to access this menu is 0.
Parameter Name
Dig In 1
Indicate the state of the signal to digital input 1
Parameter Name
Dig In 2
Indicate the state of the signal to digital input 2
Parameter Name
Enable
Indicate whether or not the power controller is enabled.
The enable signal must be on for the unit to output power
to the load
Parameter Name
SP Source
Indicate whether the power controller is local or remote set
point mode
Option Value
Off
On
Option Value
Off
On
Option Value
Off
On
Option
Local / Comms
Set Point via keypad or communication
Remote
Set Point via analog input
Description
0
1
Description
0
1
Description
0
1
Description
Description
38
User's manual
Modbus Par.
Address Type
Read
13 bit8
Only
Modbus Par.
Address Type
Read
13 bit9
Only
Modbus Par.
Address Type
Read
14 bit2
Only
Modbus Par.
Address Type
Read
14 bit1
Only
Value
2
0
