9.4.1 Operator Menu
This section describes each item on the operator menu. Use this menu to view the measured values and basic
settings of the power controller. The password to access this menu is 0.
Parameter Name
Set Point
View the set point
Volts Out
Indicates the average (RMS) voltage of all
phases
Current
Indicates the average (RMS) current of all
phases
Power
Indicates the average (RMS) power output
Volts In
Indicates the average (RMS) voltage input
Frequency
Indicates frequency of the power input
Pwr Factor
Indicates power factor of the output power
Load Ω
Indicates the resistance of the load
I Limit SP
Indicates the maximum percent of the nominal
current that the power control allows. This
parameter indicates RMS current by default.
When parameter 52 is set to 1, this parameter
indicates peak current
Out Scale
Indicates the percentage by which the power
demand set point is scaled
Nom Line V
Indicates the user-set, nominal value for the
line voltage input
Nominal I
Indicates the user-set, nominal load current
Description
29
User's manual
Modbus
Range Unit
Address
0 to 100 %
0 to 1023 V
0 to 1023 V
0 to 100 %
0 to 65535 V
0 to 655.35 Hz
0 to 1000
0 to 655.35 Ω
0 to 100 %
0 to 100.0 %
0 to 1023 V
0 to 999.9 A
Par.
Type
Read
15
Only
Read
10
Only
Read
11
Only
Read
12
Only
Read
47
Only
Read
9
Only
Read
102
Only
Read
46
Only
Read
17
Only
Read
16
Only
Read
37
Only
Read
38
Only
