Command
UARTBAUD1~8
UARTSW1~8
UARTSW0
UARTBAUD?
UARTSW?
?
Quit
Note: Any commands will not be executed unless followed by a
carriage return. Commands are case insensitive.
Description
Set output A~D's uart baud rate from
1~6
1: 9600bps
2: 14400bps
3: 19200bps
4: 38400bps
5: 57600bps
6: 115200bps
Switch output's UARTto A~H and
allow Matrix to send commands to
Receiver's connected RS-232 device.
Switch output's UART to MCU.
Restoring RS-232 control to the
Receiver output back to Matrix.
Display all the outputs UART baud
Display the UART switching state
Display all the available commands
Exit(for telnet only)
10
