6.4 Remote Control

1
2

6.5 IR Cable Pin Assignment

IR Blaster
IR Receiver
7
1 POWER: Press this button to
switch on the device or set it to
standby mode.
IN: Input ports selection 1~8.
2
OUT: Output ports selection A~H.
3
3
Power
1
IR Blaster Signal
2
NC
3
IR Signal
1
Power
2
3 Grounding
