6.7 RS-232 & Telnet Commands
Command
A1~A8
B1~B8
C1~C8
D1~D8
E1~E8
F1~F8
G1~G8
H1~H8
ABCD...1~ABCD...8
SETIP <IP> <SubNet> <GW>
RSTIP
IPCONFIG
P0
P1
STORE 01~08
PRESET 01~08
SHOW 01~08
NAME N1 N2
I1~I8
ST
RS
EM
9
Description
Switch Output A to 1~8
Switch Output B to 1~8
Switch Output C to 1~8
Switch Output D to 1~8
Switch Output E to 1~8
Switch Output F to 1~8
Switch Output G to 1~8
Switch Output H to 1~8
Switch Output A B C D... to 1~8 at the
same time
Setting IP. SubNet. GateWay (Static IP)
IP Configuration Was Reset To Factory
Defaults <DHCP>
Display the current IP config
Power OFF
Power ON
Store current I/O position(01~08)
Recall current I/O position(01~08)
Show current I/O position(01~08)
Name the stored port N1 (01~08)
no more than 8 charactors, N2
(ABCDEFG)
Switch all the Output to 1~8
Display the current matrix status and F/
W version
System Reset to A1, B2, C3, D4, E5, F6,
G7, H8
Setting EDID MODE. 1-STD 2-TV
