M-Mode Controls

Control
Sweep Speed
Anatomical M-Mode
(option)
–
Versana Essential
5759238-100 English Rev. 2
M-Mode is intended to provide a display format and
measurement capability that represents tissue displacement
(motion) occurring over time along a single vector.
Table 2-2:
Bioeffect
No Changes the speed at which the timeline is swept.
Available in M-Mode, Doppler Mode and M Color Flow Mode.
Yes Anatomical M-Mode gives you the ability to manipulate the cursor
at different angles and positions. The M-Mode display changes
according to a motion of the M cursor.
User Guide
M-Mode Controls
Description/Benefit
Optimizing the Image
2-5
