Assembly Instructions
Model 7222
Drop Leaf Cabinet Cart
GENERAL:
1. You have purchased model 7222. Overall dimensions of an assembled unit is 40" x 20" x 34.25"
when drop leaves are up.
2. Should you need assistance or need to replace a damaged or missing part, DO NOT RETURN
THE UNIT TO THE STORE where you purchased it, simply give us a call at 607-652-7321 from
7:30 - 4:00 PM Eastern time and we'll send you the prepaid part via UPS usually that same day!
3. Read the assembly instructions and the enclosed brochure before beginning assembly.
Assembly is very easy if you read and follow the instructions step by step.
4. Tools required: Phillips screwdrivers, medium and small; medium flat blade screwdriver and a
hammer.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for CATSKILL 7222
Summary of Contents for CATSKILL 7222
- Page 1 Drop Leaf Cabinet Cart GENERAL: 1. You have purchased model 7222. Overall dimensions of an assembled unit is 40” x 20” x 34.25” when drop leaves are up. 2. Should you need assistance or need to replace a damaged or missing part, DO NOT RETURN THE UNIT TO THE STORE where you purchased it, simply give us a call at 607-652-7321 from 7:30 - 4:00 PM Eastern time and we’ll send you the prepaid part via UPS usually that same day!
-
Page 2: Cabinet Parts
Back Panel (1) P/N S-7222 P/N BP-7222 15 13/16-15 1/16 15 13/16-15 13/16 Glide Support Sticks (2) P/N GSS 7222 15 7/8-1 1/2 Right Door (1) P/N DOR-7222R 15-7 3/4 Left Door (1) P/N DOR-7222L 15-7 3/4 Door Spacer (1) - Page 3 CABINET HARDWARE Bastion Post (2) (Cabinet Bolt) P/N Drop Leaf Support (2) 1 3/4” Phillips Flat Head Bolt (12) (Attaches Cabinet to Top - Front) Bastion Set Screw (2) Drawer 1 3/4” Phillips Flat Head #8 Screw (2) Cabinet 1 1/4” Phillips Flat Head #8 Screw (8) Bastion Barrel Nut (2) Drawer Glide (2 Sets ) (Door Pin)
- Page 4 TIPS ON HOW THE BASTION FASTENING SYSTEM WORKS 1. The Bastion fastening system consists of a steel post (threaded on one end with a hole through the shaft on the other end); a Barrel Nut (cylindrical barrel-shaped with Illustration Bas. 1 threaded open end &...
-
Page 5: Drawer Assembly
STEP 1 Drawer Assembly Tap in post with a hammer to start and screw down with a screwdriver or with a small allen wrench until the shoulder of the post hits the wood. Then unscrew until the hole is parallel with the groove on the bottom of the Drawer Front. - Page 6 STEP 3 Glide Assembly Left Side 1 1/4” #8 5/8” #6 Right Side The glides look almost alike however, they are labeled CR for Cabinet Right and CL for Cabinet Left. STEP 4 Note: Ok if pins are loose Brace Preparation 3/4”...
-
Page 7: Step 6 Door Assembly
Step 5 1 3/4” Machine Screws Main Assembly TIP: Place the nut on the tip of your finger and hold it against the inside of the hole as you screw in the bolt from the other side. Inside Brace Side Panel Leg Hex Nut Countersunk Hole in Leg ( disk goes in this hole to... -
Page 8: Step 7 Front Assembly
Step 7 Front Assembly 1 3/4” Machine Screws Washer Step 8 Door Magnet 1. Stick magnet to magnet plate on right door. 2. With left door open, close the right door. The magnet should be positioned over the wooden block on the bottom of the top front brace. - Page 9 Step 9 Attach Top Invert the Cart Base and posi- tion onto the Cart top. Fit the “Z” brackets into the slot across the top back brace. Align the holes in the top front brace with the pilot holes at the front of the cart top.
-
Page 10: Step 10 Main Assembly
Step 10 Main Assembly 5/8” Wooden Disk... - Page 11 Catskill Craftsmen’s factory. For Please send me______# of bottle(s) of the one eight ounce (8 fl. oz.) bottle, which Catskill Craftsmen Butcher Block Oil at $7.95 is sufficient for two applications, simply per bottle. My check or money order is send $7.95 along with the completed...
