Altronix R2432UL Series Installation Manual page 4

For fuse protected models:
Replace fuses with the same type and rating 3.5A/250V.
3.5A 250V
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the user
to the presence of an insulated DANGEROUS VOLTAGE within the product's enclosure that may
be of sufficient magnitude to constitute an electric shock.
The exclamation point within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying
the appliance.
Rack Mechanical Drawing and Dimensions:
2.95"
(75mm)
0.65" (16.5mm)
8.5"
(215.9mm)
2.52"
(64mm)
RESET
3.26"
OFF
(83mm)
32 31 30
N P N P N P N P
Altronix is not responsible for any typographical errors.
140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056
website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty | Made in U.S.A.
IIR2432ULSeries
- 4 -
CAUTION: To reduce the risk of electric shock do not open
enclosure. There are no user serviceable parts inside. Refer servicing
to qualified service personnel.
3.26" x 19.125" x 8.5" (83mm x 486mm x 216mm)
1.5"
(38mm)
29 28 27 26 25 24 23 22
N P N P N P N P N P N P N P N P
19.125" (486mm)
17.5" (444.5mm)
Front View
Bottom View
1.0"
(25.4mm)
19
21 20 18 17 16 15
N P N P N P N P N P N P N P N P
D19R
Rear View
14 13 12 11 10 9 8 7
N P N P N P N P N P N P N P N P
6 5 4 3 2 1
N P N P N P N P
MEMBER
R2432UL Series
