Directed DS4+ Installation Manual page 12

Wire Information
Function Color
Ford F150 2011-2014
RX Violet/Gray
TX Yellow/Orange
12V Green/Red
Starter Blue/White
Ignition White/Orange
Accessory Violet/Green
Keysense Blue/Gray
Parking Lights Yellow/Blue
HS CAN High White/Blue
HS CAN Low White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
Driver Door Trigger Green/Violet
Lock Blue/Green
Unlock Yellow/Violet
Tach Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange, Brown, Green/
White, Gray/Brown or
Violet/Orange
Ford F250 2011-2016
RX Yellow/Orange
TX Violet/Gray
12V Blue/Red or Green/Red
Ignition White/Orange
Starter Blue/White
Accessory Violet/Green
Keysense Blue/Gray
Parking Lights Yellow/Blue
HS CAN High White/Blue
HS CAN Low White
MS CAN High Gray/Orange
MS CAN Low Violet/Orange
Driver Door Trigger Green/Violet
Lock Blue/Green
Unlock Yellow/Violet
Tach Blue
12
Pin Polarity Location
4 Data (PATS) connector.
3 Data (PATS) connector.
4 (+) Ignition switch.
7 (+) Ignition switch.
1 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 (+) BCM in passenger kick panel.
6 Data OBDII.
14 Data OBDII.
3 Data OBDII.
11 Data OBDII.
9 Cut BCM (Body Control Module) in passenger
kick panel.
6 (-) BCM in passenger kick panel.
8 (-) BCM in passenger kick panel.
1 (AC) Any fuel injector.
4 Data (PATS) connector.
3 Data (PATS) connector.
4 (+) Ignition switch.
1 (+) Ignition switch.
7 (+) Ignition switch.
6 (+) Ignition switch.
5 (+) Ignition switch.
6 (+) SJB (Smart Junction Box) passenger kick
panel.
6 Data OBDII.
14 Data OBDII.
3 Data OBDII.
11 Data OBDII.
9 Cut SJB passenger kick panel.
6 (-) SJB passenger kick panel.
8 (-) SJB passenger kick panel.
N/A (AC) Customer Access Harness above driver
kick, taped to wiring harness. On models
without the Customer Access Harness, go
to any fuel injector and use the wire that
is not blue (gasoline), or use the camshaft
position sensor, which is white/green
at the Powertrain Control Module on
passenger side of engine, middle, black
98 pin plug, pin 32 (diesel).
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Gray
© 2017-12-13 Directed. All rights reserved.
Pins Ref.
4 A
4 A
7 B
7 B
7 B
7 B
7 B
10 J
16 C
16 C
16 C
16 C
26 I
26 I
26 I
2 N/A
4 A
4 A
7 B
7 B
7 B
7 B
7 B
10 J
16 C
16 C
16 C
16 C
26 I
26 I
26 I
2 N/A
DS4+ FORD6
