Vehicle wiring reference chart
This section provides vehicle wiring information to guide you through the various stages of your installation. Refer to
www.directechs.com for additional information.
Wire Information
Function
Color
Ford Edge 2011-2014
RX
Violet/Gray
TX
Yellow/Orange
Power Liftgate
Gray/Yellow
12V
Green/Red
Starter
Blue/White
Ignition
White/Orange
Accessory
Violet/Green
Keysense
Blue/Gray
Parking Lights
Yellow/Blue
HS CAN High
White/Blue
HS CAN Low
White
MS CAN High
Gray/Orange
MS CAN Low
Violet/Orange
Driver Door Trigger
Green/Violet
Lock
Blue/Green
Unlock
Yellow/Violet
Tach
Green/Blue, Gray/Yellow,
Violet/Gray, Yellow/
Orange, Brown or Green/
White
10
Pin
Polarity Location
4
Data
(PATS) connector.
3
Data
(PATS) connector.
6
(-)
Power liftgate switch.
4
(+)
Ignition switch.
7
(+)
Ignition switch.
1
(+)
Ignition switch.
6
(+)
Ignition switch.
5
(+)
Ignition switch.
6
(+)
BCM in drivers kick panel.
6
Data
OBDII.
14
Data
OBDII.
3
Data
OBDII.
11
Data
OBDII.
9
Cut
BCM in drivers kick panel.
6
(-)
BCM in drivers kick panel.
8
(-)
BCM in drivers kick panel.
1
(AC)
Any fuel injector.
Connector Information
Color
Black
Black
Black
Black
Black
Black
Black
Black
Gray
Black
Black
Black
Black
Black
Black
Black
Black
© 2017-12-13 Directed. All rights reserved.
Pins
Ref.
4
A
4
A
6
F
7
B
7
B
7
B
7
B
7
B
10
E
16
C
16
C
16
C
16
C
26
D
26
D
26
D
2
N/A
DS4+ FORD6
