ASSEMBLY INSTRUCTIONS
4 FT (1.2 M) LAT PULLDOWN WALL MOUNT
VERSION: XCREATE-LPDWM
PART # 5676001-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the XCREATE-LPDWM and is the answer not in the manual?

Questions and answers

Related Manuals for Torque XCREATE-LPDWM

Summary of Contents for Torque XCREATE-LPDWM

  • Page 1 ASSEMBLY INSTRUCTIONS 4 FT (1.2 M) LAT PULLDOWN WALL MOUNT VERSION: XCREATE-LPDWM PART # 5676001-A...
  • Page 2 ITEM PART NUMBER DESCRIPTION ITEM PART NUMBER DESCRIPTION 56641PA PTD ASSY, LOWER WALL MOUNT 5581301 COVER, FRONT BASE 56472PA PTD ASSY, ROW BASE 2005509 BOLT, 1/4-20 X 3/8" (9mm) SOCKET HEAD 2001301 WASHER, FLAT 1/2 SAE ST ZN 5674801 WLDMT, ALUMINUM ROW HANDLE 2006803 BOLT, 1/2-13 X 1"...
  • Page 3 STEP 1 CABLE NOTE 2: BEFORE ASSEMBLING ROW BASE, ROUTE THE CABLE THROUGH THE SLOT AND BEHIND THE BRACKET OF THE LOWER WALL MOUNT 1/2" FLAT WASHER (2) LOWER WALL MOUNT 1/2 X 1" BOLT (2) NOTE 3: BEFORE TIGHTENING BOLTS, MAKE SURE THAT THESE TWO SURFACES ARE FLUSH ROW BASE NOTE 1:...
  • Page 4 STEP 2 WALL BASE PLATE LOWER WALL MOUNT NOTE: BEFORE ANCHORING LOWER WALL MOUNT TO THE WALL, ADJUST LEVELERS (2) SO THAT THE BASE PLATE IS LEVEL WITH THE FLOOR. 3/8" FLAT WASHER (4) 3/8" LAG BOLT (4) NOTE: (TYPICAL FOR 2-1/2"...
  • Page 5 STEP 3 3/8" FLAT WASHER (2) 3/8 X 4-3/4" BOLT (2) ROW BASE NOTES: SECURELY tighten bolt connections in this step.
  • Page 6 STEP 4 LOWER WALL MOUNT 3/8" FLAT WASHER (4) 3/8 X 3/4" BOLT (2) LEFT SHROUD BASE NOTES: SECURELY tighten bolt connections in this step.
  • Page 7 STEP 5 LOWER WALL MOUNT 3/8" FLAT WASHER (2) 3/8 X 3/4" BOLT (2) RIGHT SHROUD BASE NOTES: SECURELY tighten bolt connections in this step.
  • Page 8 STEP 6 GUIDE ROD RETAINER (2) SHAFT COLLAR (2) GUIDE ROD (2) HEAD PLATE 15 LB WEIGHT PLATE (10) 20 LB WEIGHT PLATE (5) CABLE NOTE: WEIGHT STACK CUSHION (2) INSERT THE GUIDE RODS THROUGH THE ROW BASE AND DOWN TO TOP OF BOLTS ROW BASE...
  • Page 9 STEP 7 3/8 X 3/4" BOLT (2) CABLE WEIGHT SELECTOR STORAGE PLATE HEAD PLATE NOTES: SECURELY tighten bolt connections in this step.
  • Page 10 STEP 8 NOTE 2: ROUTE THE CABLE AROUND THE PULLEY BEFORE ASSEMBLING 4-1/2" PULLEY IT TO THE ROW TOP BOOM 3/8" FLAT WASHER (2) ROW TOP BOOM 3/8" LOCK NUT (2) NOTE 4: NOTE 3: NOTE 1: MAKE SURE THE CABLE IS ROUTE THE CABLE THROUGH THE ROUTE THE CABLE THROUGH THE IN THE GROOVE OF THE...
  • Page 11 STEP 9 ROW TOP BOOM NOTE: MAKE SURE THE CABLE IS ROUTED NOTE: AROUND THE PULLEY OF THE ROW TOP BOOM BEFORE TIGHTENING BOLTS, MAKE SURE THAT THESE TWO SURFACES ARE PARALLEL 1/2 X 1" BOLT (2) 1/2" FLAT WASHER (2) NOTE: MAKE SURE THE CABLE NOTE:...
  • Page 12 STEP 10 UPPER WALL MOUNT NOTE: MAKE SURE THE UPPER 16" WALL MOUNT IS LEVEL 3/8" FLAT WASHER (4) (40.6 CM) WARNING: 3/8" LAG BOLT (4) 2-1/2" THE UPPER WALL MOUNT MUST BE (TYPICAL FOR (6.4 CM) ANCHORED TO THE WALL USING FOUR WOOD STUDS) WALL ANCHORS SUITABLE FOR THAT PATICULAR WALL CONSTRUCTION...
  • Page 13 STEP 11 ROW TOP BOOM NOTE: SLIDE THE GUIDE ROD RETAINERS UP INSIDE THE GUIDE ROD RETAINER (2) ROW TOP BOOM. SLIDE THE SHAFT COLLARS UP INSIDE SHAFT COLLAR (2) OF THE GUIDE ROD RETAINERS AND SECURELY TIGHTEN THE SET SCREWS OF THE SHAFT COLLARS GUIDE ROD (2) NOTES: SECURELY tighten bolt connections in this step.
  • Page 14 STEP 12 NOTE: THE HOUSING ON THE CABLE SHOULD BE AT LEAST 1/2" AWAY FROM THE SWIVEL PULLEY. IF THE HOUSING IS TOUCHING THE SWIVEL PULLEY, THEN THE CABLE NEEDS TO BE ADJUSTED. LOOSEN JAM NUT AND TURN THE THREADED END OF THE CABLE COUNTER CLOCKWISE UNTIL THE HOUSING IS 1/2"...
  • Page 15 STEP 13 NOTE: NOTE: MAKE SURE THE SHROUD MAKE SURE THE SHROUD IS SEATED BETWEEN THE IS SEATED BETWEEN THE SHROUD SUPPORT AND SHROUD SUPPORT AND THE FOUR TABS AS SHOWN. THE FOUR TABS AS SHOWN. TOP VIEW LEFT TOP VIEW RIGHT RIGHT SHROUD BASE FRONT SHROUD (2) LEFT SHROUD BASE...
  • Page 16 STEP 14a 1/4 X 1/2" BOLT (4) 1/4" FLAT WASHER (4) TOP CAP NOTE: MAKE SURE INTERNAL GROOVES OF UPPER WALL MOUNT THE TOP CAP FIT DOWN OVER THE TOP EDGES OF BOTH FRONT SHROUDS. FRONT SHROUD (LEFT SIDE) FRONT SHROUD (RIGHT SIDE) NOTES: LOOSELY tighten bolt connections in this step.
  • Page 17 STEP 14b 1/4 X 1/2" BOLT (2) 1/4" FLAT WASHER (2) TOP CAP ROW TOP BOOM NOTES: SECURELY tighten bolt connections in this step, and previous step.
  • Page 18 STEP 15 NOTE CENTER PLACARD ON SHROUD SURFACE. PLACARD FRONT SHROUD (RIGHT SIDE) 57-1/2" (146 CM) 2-1/4" (5.7 CM)
  • Page 19 STEP 16 ROW BENCH FRAME NOTE: MAKE SURE THE BASE PLATE SITS FLAT ON THE FLOOR 1/2" X 3" BOLT (4) BEFORE TIGHTENING 1/2" FLAT WASHER (8) 1/2" LOCK NUT (4) ROW BASE NOTES: SECURELY tighten bolt connections in this step. Some parts have been hidden for illustration clarity.
  • Page 20 STEP 17 ROW FOOT SUPPORT 1/2" FLAT WASHER (6) 1/2" LOCK NUT (3) 1/2 X 4-1/4" BOLT (3) ROW BENCH FRAME NOTES: SECURELY tighten bolt connections in this step. Some parts have been hidden for illustration clarity.
  • Page 21 STEP 18 BACK PAD ROW BENCH FRAME 3/8" FLAT WASHER (3) 3/8 X 3" BOLT (3) NOTES: SECURELY tighten bolt connections in this step.
  • Page 22 STEP 19 1/4 X 3/8" BOLT (2) 1/4" FLAT WASHER (2) ROW BENCH FRAME NOTES: FRONT BASE COVER SECURELY tighten bolt connections in this step.
  • Page 23 STEP 20 SNAP HOOK ROW HANDLE...

  • Page 24: Maintenance

    MAINTENANCE GUIDE RODS: Clean and lubricate with a silicone or teflon based lubricant INSPECTION: Once a month, check for loose bolts. Tighten if necessary. CABLES: Check tension, end fitting and cable coating. Replace if damage or worn. (NOTE: NEW CABLES ALWAYS STRETCH DURING USE.
