Image Quality Tests and Patterns

How to get here
Tools Screen 1
More
Tools Screen 2
Machine Tests
Machine Tests
Image Quality
These tests and test patterns help in troubleshooting the Xerographic
Tests and
System. These tests are designed to be interpreted by an authorized
Patterns
Xerox Representative or by you with assistance from the Welcome
Center.
Image Quality Tests
The machine has a variety of tests that are designed to determine
problems or faults with the Xerographic System. Each test produces
a pattern or patterns that can be used to evaluate the printing
capability of a particular aspect of the Xerographic System.
Image Quality Patterns
The Image Quality Patterns are simply documents that are resident
in memory that, when printed, test and validate the functionality of
the Xerographic System.
Page 6 - 38 Xerox Document Centre Reference Guide
