What you need to know about your Document Centre 240/255/265 LP/ST
FRONT VIEW
2
1
1.
Bypass Tray (Tray 5) and High Capacity Feeder (Tray 6)
2.
User Interface (see Details on the back of this card)
3.
Document Feeder (ST model ONLY, with scanner glass
underneath)
4.
Power Switch (you will use this during network installation)
5.
Finisher (for stapling and offset collation)
6.
Paper Trays 1-4
3
4
6
5
Page 1
BACK VIEW
2
1
1.
Power Cord connection
2.
Card Cage Ports Panel
3.
Ethernet Port (RJ45)
4.
Optional Token Ring Interface (if your printer is so
equipped, a short cable with an RJ45 connector attached
will connect here)
5.
Active Phone Line Port
3
4
5
