4.5 Line status

The line status of all the lines can be viewed as follows:
Press the < and > keys (numeric 4 and 6) to select a channel/line you
want information about.
L06 ???
Free.
The top line will display the selected channel/line number followed by
the local phone. To the right is the remote number. In between the local
and remote numbers there is an arrow for the call direction. An arrow
pointing to the left is an incoming call, an arrow pointing to the right is
an outgoing call. The second line in the display indicates if the line is
used in case a call is going on
L03 3471000
Recording.
In this case the channel/line 3 is used for an incoming call from the
remote number 793479336 to the local number 3471000. The channel is
recording and the call has been going on for 4 minutes and 36 seconds.
You can also see there is one line busy at that moment. The numbers of
the calls remain in the display of the channel after the call has ended, it
will however indicate the line is "Free".
Use the and
to scroll through the busy lines with the

4.6 Monitoring

Monitoring of the telephone lines is a feature of the Call Recorder that
allows the user to listen in on the recording of the telephone
conversations.
48 Call Recorder ISDN manual © 2010-2014 Vidicode®
- (no number)
Lines Busy = 0
<- 793479336
Lines Busy = 1
keys to scroll through the channels. It is possible
04:36
key.
