Relay Module: 12 Relays

RELAY 1 RELAY 2
RELAY 3
NO/NC C NO/NC C C
NO/NC

Relay Modules: Six Relays

RELAY 1 RELAY 2 RELAY 3
NO/NC C NO/NC C NO/NC

Polarity reversal/city tie

JW4
FA-301-8LDW
FA-301-8LW
RELAY 4 RELAY 5 RELAY 6 RELAY 8
RELAY 7
NO/NC C NO/NC C NO/NC C C NO/NC C NO/NC
NO/NC
RELAY 4 RELAY 5 RELAY 6
C NO/NC C NO/NC C NO/NC C
FA-300 Series LED Version Installation and Operation Manual
8 Zone Fire Alarm Control Panel with LED
display (white door, black box). 8 Class B
(Style B) Initiating circuits, and four Power
Limited Class B (Style Y) Indicating circuits
(up to1.70 amperes each, 5 amperes total).
Two six zone ICAC-306 Input Class A
converter adder modules may be used for
Class A (Style D) wiring of Initiating circuits.
One OCAC-304 Output Class A Converter
adder module may be used for Class A (Style
Z) wiring of the Indicating circuits. The FA-
301-8LDW contains Common Alarm, Common
Supervisory & Common Trouble Relays,
auxiliary alarm relay (disconnectable), an RS-
485 Interface for Remote Annunciators and a
Resettable Four Wire Smoke Detector Power
Supply. The unit has a dialer on main board.
Used with BA-110 (10 amp-hour) (Sota Enertech
model SA12120) batteries (two required).
8 Zone Fire Alarm with LED display (white door,
black box). Same as FA-301-8LDW except
without dialer.
RM-312
RELAY 9 RELAY 10 RELAY 12
RELAY 11
C NO/NC C C NO/NC C
NO/NC
PR-300
Model Description
Twelve-relay adder module
Model Description
RM-306 Six-relay adder module
Model Description
Polarity Reversal and/or City
tie Module
