If D3 Boot Status LED not turning OFF
If D3 Boot Status LED not turning OFF.
►
Check the serial console log. The image shows the normal
►
boot log.
If
Boot sequence is not normal try re-flashing the SD Card
►
Image.
SD Card Image download link: To be added.
►
To write SD card use win32 disk imager or similar tool.
https://wiki.analog.com/resources/tools-software/linux-
software/zynq_images/
windows_hosts?s[]=sd&s[]=card&s[]=write#flash_the_sd_card
Boot sequence is normal issue could be with the ADS9 board
►
itself. Try swapping the board or contact ADI Support
https://ez.analog.com/wide-band-rf-transceivers/design-support-adrv9026/
