7.3 DESCRIBING BRIDGE STATISTICS

Table 7-1 lists and describes Bridge Statistics screen fields that provide
information about activity on the bridge ports.
Table 7-1 Source Route Bridge Statistics Fields
Field
Ring Number
Frames
Received
Frames
Transmitted
Frames
Discarded
Description
Indicates the ring numbers assigned to the Station and FNB
bridge ports.
Displays the number of Source Routed, All Routes
Broadcast, and Single Route Broadcast frames received by
the Station and FNB ports.
Displays the number of Source Routed, All Routes
Broadcast, and Single Route Broadcast frames transmitted
by the Station and FNB ports.
Displays the number of source route bridge frames
discarded because of duplicate segments, segment
mismatches, or exceeded hop count limits by the Station
and FNB ports.
BRIDGE STATISTICS SCREEN
7-3
