7. LED signaling
LED signalling
Red LED
Yellow LED
8. Electrical parameters
Dimension
Operating position
Operating condition
Power supply
(optionally integrated ACU 2000mAh for cca 48h of operation)
Buttons
Relay 2x
Max. voltage
Max. Current
Activation time by code
Activation time by SMS
Input:
GSM:
networks
SIM
WebHill.fi -Verkkokauppa
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
Permanent light
Permanent light
Power supply is ON
¤¤¤¤¤¤¤¤¤¤¤
GDI power supply is ON
Not light
Not light
GDI switched OFF
GDI switched OFF
Not light
Not light
GDI switched OFF
GDI switched OFF
Flashing space and light same duration
Flashing space and light same
¤¤¤
¤¤¤
¤¤¤
Not registered to GSM network
duration
GDI is not registrated to GSM network
Short flashing with frequency 2 sec.
Short flashing with frequency 2 sec.
▌
▌
▌
Registered to GSM network
GDI registrated to GSM network
Permanent light
Permanent light
¤¤¤¤¤¤¤¤¤¤¤¤
GDI establish a call or it is a call
Establish a call or it is a call
185 mm x 99 mm x 40 mm
various
temperature: -20 to + 50°C
Humidity: 10% ÷ 80% at 30° C
12 (9-24) V AC/DC, 200mA
1 (or optional 2)
switching contact
48V when I<1A
2A when U<30V
1 to 99 sec
1 to 99 min
0/5V
33
850/900/1800/1900 MHz
3V, 1.8V
Copyright © 2011 – Linkcom – All rights reserved
24
