number. If the SIM card already contents even one number under name "ADMINx", the command
is ignored.
2. If you need to control the GSM DoorPhone with a next ADMIN numbers: from mobile phone with
"ADMINx" number, send the SMS to the GSM DoorPhone with numbers of next "ADMINx" in SMS
format: WRITE ADMIN2 +33xxxxxxxxx (WRITE ADMIN3... etc.).
3. From mobile phone with numbers "ADMINx" send the SMS to the GSM DoorPhone with numbers,
which should be dial after button press.
SMS format: WRITE ABUTTON1 +33xxxxxxxxx
4. Up your needs send next SMS with other parameters for opening by ringing, SMS alarm sending,
etc..
5. You can setup individually for each parameter with appropriate SMS. When you need setup more
parameters simultaneously, we recommend use SMS for batch setting. By SMS "READ PAR" to
read firstly current setting to your mobile.
By editor of SMS messages change at received SMS word READ to WRITE as same as adjust
parameters up your needs. Such adjusted SMS send back to GSM DoorPhone as reply. The
parameters will be setup.

4.2. Setting by PC through USB via Link GSMDoorManager (optional)

Remove front cover of the GSM DoorPhone and connect the MiniUSB cable to PC and programming
module. The red LED must light on at the module. During first usage, the USB driver might be installed.
USB driver is available at attached CD or on
1. Run Link GSMPhone Manager program and setup the appropriate port.
2. You can program the GSM DoorPhone after that display GSM signal strength and voltage (back up
ACU). Now you can program:
