BBUTTON5
BBUTTON6
BBUTTON7
ADMIN2 to ADMIN7
ADMIN1
Various name
ALARMON
ALARMOFF
VER
PARGDI
Linkcom France
11 rue du Soleil Levant 92140 CLAMART
- It's the called number when you push the button, if
BBUTTON4 is busy, unreachable, or not picked up.
- Relay1 or relay2 are activated by ringing in
- Calls are automatically received from this number
- It's the called number when you push the button, if
BBUTTON5 is busy, unreachable, or not picked up.
- Relay1 or relay2 are activated by ringing in
- Calls are automatically received from this number
- It's the called number when you push the button, if
BBUTTON6 is busy, unreachable, or not picked up.
- Relay1 or relay2 are activated by ringing in
- Calls are automatically received from this number
- Relay1 or relay2 are activated by ringing in.
- Relay1 or relay2 are by SMS
- Read the GSM DoorPhone status and numbers in phone
book by SMS
- Edit name and numbers on SIM card by SMS
- Control next features by SMS (AT commands)
- Setup parameters by SMS
- Calls are automatically received from this number
The same like ADMIN2 to ADMIN7 and more over:
- This number can receive the reports by SMS, includes
list of relay activation by ringing in
- This number can receive the SMS about low battery
level (option).
- Relay1 or relay2 are activated by ringing in.
- calls are automatically received from this number
- This number receives the "ALARM ON" SMS when input
is activated against ground
- This number receives the "ALARM OFF" SMS when input
is activated against ground
- firmware version in GDI - just info – do not adjust!
- GSM DoorPhone parameters A#B#C#D#E#F#G#H
(default is 4#4#0#0#1#5#0#0)
A : microphone sensitivity [1-7]
B : speaker loudness [1-7]
C : incoming calls:
0 : all rejected (ringing in relays activation)
1 : accept from numbers on SIM card only
2 : accept all
D : record who opened by ringing in :
0 : deactivated
1 : activated
E – time setup from GSM network:
0 : deactivated
1 : activated
F : signalization:
0 : OFF
