Connecting AC and RPS-SYS Power

Connecting AC and RPS-SYS Power

AC Power

To connect a switch to the AC power source, refer to Figure
1. Plug the power cord into the switch AC power connector.
2. Plug the other end of the power cord into a dedicated grounded AC outlet (not
shown). The type of power outlet and power cord are country‐dependent.
3-12 Hardware Installation
Note: The power supply in the switch has automatic voltage sensing that allows
connection to power sources ranging from 100 to 240 VAC.
Note: If you plan to connect all the switches quickly to allow automatic Manager selection,
wait until all switches are fully operational before proceeding to the next step.
If you plan to power up each switch and allow it to become fully operational before
applying power to the next switch, proceed to the next step.
3‐6 and proceed as follows:
