2.2 TPS3899EVM Bill of Materials

Designator Quantity
!PCB1 1
C1, C2, C3 3
H1, H2, H3, H4 4
J1, J2, J3, J4, J6 5
J5 1
R1, R3 2
R2 1
SH-J3, SH-J4, SH-J5 3
TP1, TP2, TP3, TP4, TP5, 6
TP6
U1 1
FID1, FID2, FID3 0
SLVUBZ3 – SEPTEMBER 2020
Submit Document Feedback

Table 2-1. TPS3899EVM Bill of Materials

Value Description
Printed Circuit Board
0.1uF CAP, CERM, 0.1 uF, 10 V,
+/- 10%, X7R, 0603
Bumpon, Hemisphere,
0.44 X 0.20, Clear
Header, 100mil, 2x1, TH
Header, 100mil, 4x1, TH
10.0k RES, 10.0 k, 1%, 0.1 W,
0603
47.5k RES, 47.5 k, 1%, 0.1 W,
0603
Shunt, 100mil, Tin plated,
Black
Test Point, Miniature, SMT Test Point, Miniature, SMT
Nano 125 nA IQ, 1%
Accurate Voltage
Supervisor, Push-Button
Monitor with
Programmable Sense and
Reset Delay
Fiducial mark. There is
nothing to buy or mount.
Copyright © 2020 Texas Instruments Incorporated
PackageReference PartNumber
LP040
0603 C0603C104K8RACTU
Transparent Bumpon SJ-5303 (CLEAR)
Header, 2x1, 100mil, TH 800-10-002-10-001000
Header, 4x1, 100mil, TH 800-10-004-10-001000
0603 RC0603FR-0710KL
0603 RC0603FR-0747K5L
Shunt Connector Black Open SNT-100-BK-T-H
Top, 2x1
5019
WSON6 TPS3899DL01DSER
N/A N/A
Schematic, Bill of Materials, and Layout
Manufacturer
Any
Kemet
3M
Mill-Max
Mill-Max
Yageo
Yageo
Samtec
Keystone
Texas Instruments
N/A
TPS3899EVM Voltage Supervisor User Guide 5
