The CD800 Card Printer

C
B
A
A = Card Input Hopper
B = Swingarm
C = Printhead
D = Manual Advance Knob
E = Latch Button
F = Cover Ridges
Front Panel
Power
Button
527980-001C
E
D
L
G = Multi-Hopper Printer Supplies
H = Multi-Hopper Cover
I = Card Output Hopper
J = Front Panel
K = Exception Slot
L = Ribbon Cartridge Handle
Up
Down
Enter
Arrow
Arrow
User Reference Guide
F
K
J
I
Access Door
LCD Front Panel
Status Lights
Ribbon
Cards
User Light &
User Button
G
H
