Secton 18 - Optons
NOTE: ATTACH RELAY
TO UPR LEFT CORNER
OF MOUNT BRACKET.
CONNECTS TO INVERTER RELAY TERMINAL 87
CONTROL
SIDE
ILLUSTRATION No.
1330SE / MICRO13-XD
ART_5830
Page 72

900W Inverter

900W Inverter
8
9 4
CONNECT TO BATTERY GROUND.
4
7
1330SE - Servce & Parts Manual
CONNECT TO BATTERY
CONNECT TO NEGATIVE SIDE OF DC CONTACTOR
CONNECT TO POSITIVE SIDE OF DC CONTACTOR
10
1
CONNECT TO
INVERTER
GROUND
2
6
CONNECT POWER TO
PLATFORM CABLE HERE:
BROWN = LINE
BLUE
Y/G
3
4
November 2021
CONNECT TO INVERTER NEG
CONNECT TO INVERTER POS
CONNECT TO INVERTER NEG
= NEUTRAL
= GROUND
4 3
900W Inverter
5
