Mec 1330SE Service & Parts Manual page 57

Secton 14 - Scssor
Item
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
Page 53
Part Number
41576 Pin
44047 Inner Arm 4
44049 Outer Arm 3
41352 Cable Bridge
44046 Inner Arm 3
41577 Pin
41263 Safety Arm
41262 Safety Arm Bushing
44045 Inner Arm 2
41256 Chassis Slider
41338 Pin
41349 Pin
44044 Inner Arm 1
53256 Screw HHCS M06-1.00 × 16 Serrated Flange
42449 Pin
41345 Pin
44048 Outer Arm 1
50386 Screw CSCS M06-1.00 × 25
41350 Pothole Pusher
50568 Nut NNYL M06-1.00 Flange
41258 Pin
53357 Screw HHCS M06-1.00 × 55 Flange
REF Lift Cylinder Assembly (Refer To Page 64)
44050 Collar
53269 Screw CSCS M05-0.80 × 16
41287 Bearing
53255 Screw HHCS M06-1.00 × 20 Serrated Flange
42446 Bearing
41343 Outer Arm 2
41114 Block
42457 Pin
41354 Washer
42437 Circlips
41256 Platform Slider
1330SE - Servce & Parts Manual
Description
November 2021
Qty.
1
1
1
3
1
9
2
2
1
2
2
2
1
2
2
2
1
2
1
6
1
4
1
4
4
44
2
26
4
32
1
26
26
2
