Mec 1330SE Service & Parts Manual page 41

Secton 13 - Chasss
Item
1
--
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
Page 37
Part Number
41223 Steer Cylinder Assembly
41594 Seal Kit
41298 Straight Fitting
41318 Cover
41794 Screw
41322 Cotter Pin
41321 Pin
41225 Bearing
43564 Washer
41210 Bearing
44043 Steer Yoke Weldment
41228 Wheel
50003 WSHR M12 Standard Flat Washer
53363 Castle Nut M12-1.75, Hex Thin Slotted
41323 Cover
53348 Screw THMS M04-0.70 × 10
41230 Bearing Cover
53269 Screw CSCS M05-0.80 × 16
44493 Cotter Pin
44029 Key
41233 Wheel Shaft
41024 Bearing
41234 Connection Plate
50429 Screw HHCS M10-1.50 × 25 Serrated Flange
41327 Washer
53347 Castle Nut M16 × 1.50
41328 Cap
53282 Screw CSCS M08-1.25 × 20
44042 Steer Yoke Weldment
41222 Bearing
41221 Tie Rod
50311 Nut NNYL M10-1.50 Flange
41199 Washer
41202 Bearing
1330SE - Servce & Parts Manual
Description
November 2021
Qty.
1
1
2
2
2
4
2
4
2
4
1
2
2
2
2
6
2
8
2
2
2
4
2
12
2
2
2
12
1
2
1
2
2
4
