Secton 15 - Platform
Item Part Number
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
Page 57
53281 Nut NNYL M05-0.80 Flange
43319 Manual Box
53223 Screw THMS M05-0.80 × 16
41283 Front Rail
50313 Nut NNYL M08-1.25 Flange
53409 Screw HHCS M08-1.25 × 80 Flange
53358 Screw HHCS M08-1.25 × 50 Flange
44586 Extension Deck Weldment
50038 Screw HHCS M12-1.50 × 25
53148 WSHR M12 Spring Washer
50003 WSHR M12 Standard Flat Washer
REF Platform Locking Device Assembly (Refer To Page 62)
43618 Circlips
41131 Bearing
41141 Roller 2
53279 Screw CSCS M05-0.80 × 12
41284 Slide Pad
41360 Roller Bracket
53280 Screw CSCS M08-1.25 × 55
44812 Right Extension Rail
44800 Left Extension Rail
41120 Bumper
53378 Screw PHMS M05-0.80 × 12
REF - Reference
1330SE - Servce & Parts Manual
Description
November 2021
Qty.
4
1
4
1
12
4
8
1
2
2
2
1
2
2
2
8
2
2
8
1
1
2
2
