Initializing TPM for users

Steps
1. Initialize the TPM.
For more information, see
2. The TPM Status changes to Enabled, Activated.

Initializing the TPM 1.2 for users

Steps
1. While booting your system, press F2 to enter System Setup.
2. On the System Setup Main Menu screen, click System BIOS > System Security Settings.
3. From the TPM Security option, select On with Preboot Measurements.
4. From the TPM Command option, select Activate.
5. Save the settings.
6. Restart your system.

Initializing the TPM 2.0 for users

Steps
1. While booting your system, press F2 to enter System Setup.
2. On the System Setup Main Menu screen, click System BIOS > System Security Settings.
3. From the TPM Security option, select On.
4. Save the settings.
5. Restart your system.

Control panel

This is a service technician replaceable part only.

Removing the control panel cage

Prerequisites
1. Follow the safety guidelines listed in the
2. Follow the procedure listed in
3. Disconnect all peripherals that are connected to the control panel.
4. Disconnect the control panel cable and control panel USB cable from the system board.
CAUTION: Do not use excessive force when removing the control panel cables as it can damage the
connectors.
5. Remove the front bezel.
Steps
1. Using the Phillips 1 screwdriver, remove the screws that secure the control panel cage to the system.
2. Slide the control panel cage out of the system along with the cables.
68 Installing and removing system components
