Table 2. Rear view of the system (continued)
Item
Ports, panels, or slots
6
USB 2.0 port (4)
7
System identification button
8
NIC ports (2)
9
USB 3.0 port
10
USB 2.0 port
11
NIC ports (1)
12
iDRAC ethernet port
13
VGA port
14
Serial port
15
PSU Built-in Self-Test (BIST) LED
16
Power supply unit plug
NOTE:
For more information, see the Dell EMC PowerEdge T150 Technical Specifications on the product documentation
page.
Icon
N/A
N/A
Descriptions
The USB ports are 4-pin, 2.0-compliant. These
ports enable you to connect USB devices to the
system.
Press the system ID button:
● To locate a particular system within a rack.
● To turn the system ID on or off.
To reset iDRAC, press and hold the button for
16 seconds.
NOTE:
● To reset iDRAC using system ID, ensure
that the system ID button is enabled in
the iDRAC setup.
● If the system stops responding during
POST, press and hold the system ID
button (for more than five seconds) to
enter the BIOS progress mode.
The NIC ports that are integrated on the
system board provide network connectivity.
These NIC ports can also be shared with iDRAC
when iDRAC network settings are set to shared
mode.
The USB ports are 9-pin, 3.0-compliant. These
ports enable you to connect USB devices to the
system.
The USB ports are 4-pin, 2.0-compliant. These
ports enable you to connect USB devices to the
system.
The NIC ports that are integrated on the
system board provide network connectivity.
These NIC ports can also be shared with iDRAC
when iDRAC network settings is set to shared
mode.
Enables you to remotely access iDRAC. For
more information, see the Integrated Dell
Remote Access Controller User's Guide at
www.dell.com/poweredgemanuals.
Enables you to connect a display device to the
system.
Enables you to connect a serial device to the
system.
Enables you to check the power supply to the
PSU.
Enables you to install cabled AC PSU.
PowerEdge T150 system overview
11
