Connectors, Adapters and Cable Connections
10BaseT Port (8-pin MJ) Connector
Figure B-2 shows the 8-pin MJ crossover connector and its pin assignments.
Table B-2 describes the pin assignments.
Pin
1
2
3
4
B-4
Figure B-2. 8-pin MJ Connector
Pin
1
Table B-2. 8-pin MJ Connector Assignments
Assignment
RX+
RX-
TX+
Unused
8
Pin
Assignment
5
Unused
6
TX-
7
Unused
8
Unused
NPG-8719-95F
