Installing and Cabling

Cabling the SSR-520

Figure 2-4 shows the SSR-520 router and cables. The table following the
figure describes how to cable the router.
Step
1
2
2-8
Figure 2-4. Installing the
Action
Connect the cable from the power supply to the power connector
(1) on the back of the router.
Plug the ac power supply cable (2) into the power supply, then
into a wall outlet.
SSR-520
Router
